Two-component Extruder

FOB Price

US$ 7,720 - 13,300 / Set

1 Set(Min. Order)

Port QingDao Port
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Machine Type	Glass Coating Machine	Place of Origin	Shandong, China
Brand Name	YUEFENG	Model Number	BST03
Certification	CE	Warranty	1 year
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Introduction

1 The curing agent is provided with a filter device, high pressure safety protection device in the pipe line, to ensure the operating more safety. The system is a closed system, put an end to the air and avoid curing agent contacting with the air and curing, to ensure that the media flow stability.

2 The high pressure valve of base material pump, curing agent pump and proportional pump adopt zero leakage of special alloy grinding, has a unique and convenient adjustable proportioning mechanism, ensure the bi-component sealant almost harsh ratio requirements.

3 The mixing system used precision stainless steel mixer, mixing mandrel, with the specially designed unidirectional needle valve to ensure the mixing evenly.

Technical Parameter

Model	BST03
Mix ratio	6:1~14:1
Charging basket	200L
Curing agent basket	20L
Max. air consumption	0.8 cbm/min
Squeeze pressure	30Mpa
Air pressure	0.6~1.0Mpa
Output	4~10L/min
Overall dimension	1100×950×1980mm
