Insulating Glass Processing Machine Two-component Extruder
- Qingdao
- T/T
You May Like
-
Insulating Glass Processing Machine Automatic Spacer Bending Machine
-
Two-component Extruder
-
Insulating Glass Processing Machine Glass Edge Grinding Machine
-
Insulating Glass Processing Machine Two-component Extruder
-
Insulating Glass Processing Machine Butyl Extruder
-
Insulating Glass Machine Heated Roller Press
Product Details
| Place of Origin | Shandong, China | Brand Name | JINANYUEFENG | |
| Model Number | BST08 |
Product Description
Specifications
1.easy operation2.reliable performence
3.advenced technique
nvenient
Introdction:
- Pump of A and B component all adopt pneumatic system driver , reversing is nimble
and reliable ,the efficiency is much more improved.
- Optimize the pipeline, increase the main motor power, to make the discharging more
rapid and fluent.
- The curing agent system, is fully enclosed system, to eliminate the air enter into, avoid
the contact of the air and curing agent (to the silicone glue curing agent), improve the
mixing effect. At the same time, this system passed four filtering, ensure the curing
agent clean and the stability of system, extend the life of pump body.
- The high pressure valve port of base material pump and the curing agent pump and the
proportioning pump all adopt zero leak special alloy grinding manufacturing, there is a
simple and easy adjustable ratio institutions in theproportioning pump, it can ensure
the almost harsh matching requirements of the two component glue to meet the
proportion of glass curtain wall and insulating glass.
Technical Parameter
Mixing ratio | 6:1~14:1 |
Material drum | 200L |
Curing agent drum | 20L |
Max. air consumption | 0.8 cbm/min |
Max. dispensing Pressure | 30Mpa |
Output | 4~10L/min |
Air supply pressure | 0.8~1.0Mpa |
Overall dimension | 1420×900×2500mm |
