Home > Products > Water Pumps > 1HP/750W CPM158 Centrifugal Water Pump
1HP/750W CPM158 Centrifugal Water Pump
- 30000 Piece / Pieces per Month
- FUZHOU
- T/T
You May Like
-
750W Copper Wire QB80 Peripheral Pump
-
370W/500W Aluminum Wire QB70 Peripheral Pump
-
600W~1100W JTP100 Stainless Steel Self Priming JET Garden Pump
-
370W~1100W Cast Iron/Stainless Steel Body with 19L/24L Tank Booster Garden Pump
-
PPO Impeller 370W JET40 Cast Iron Self Priming JET Garden Pump
-
370W/500W 100% Copper Wire QB60 Peripheral Pump
Product Details
| Place of Origin | Fujian, China | Brand Name | OEM | |
| Model Number | CPM serie | Theory | Centrifugal Pump | |
| Structure | Single-stage Pump | Usage | Water | |
| Power | Electric | Standard or Nonstandard | Standard | |
| Fuel | Other, clean water | Pressure | Low Pressure | |
| Application | Other, clean water |
Product Description
1HP/750W CPM158 Centrifugal Water Pump
1. Working conditions:
Max temperature of fluid up to: 80℃
Max ambient temperature up to: 40℃
Max Pressure: 10bar
2. Structural characteristics:
Pump casing: Cast iron
Impeller: Brass
Motor housing: Aluminum
Mechanical seal: Stainless steel(graphite to ceramic)
Shaft: 45# steel or stainless iron
Bearing: SKF/NTN/NSK/China
Insulation class: B and F
Protection class: IP44 and IP54
3.Technical data(220V,50HZ)
CPM Seires
Model | Power | Q.MAX (L/min) | H.MAX (m) | S.Head (m) | Speed (r.p.m) | Pipe Dia (Inch) | N.W (kg) | Packing size (mm) | |
W | HP | ||||||||
CPM-130 | 400 | 0.54 | 100 | 20 | 9
9 | 2850
2850 | 1” * 1”
1” * 1”
| 8.8 | 265*165*215 |
CPM-146 | 550 | 0.75 | 100 | 26 | 12.2 | 300*175*230 | |||
CPM-158 | 750 | 1 | 108 | 32 | 13.6 | 310*190*245 | |||
CPM-180 | 1100 | 1.5 | 120 | 40 | 20.2 | 361*230*292 | |||
CPM-200 | 1500 | 2 | 130 | 46 | 23 | 361*230*292 | |||
SCM Seires
Model | Power | Q.MAX (L/min) | H.MAX (m) | S.Head (m) | Speed (r.p.m) | Pipe Dia (Inch) | N.W (kg) | Packing size (mm) | |
W | HP | ||||||||
SCM-22 | 400 | 0.54 | 100 | 20 |
9 |
2850 |
1″* 1″ | 9.4 | 280*157*210 |
SCM-42 | 550 | 0.75 | 115 | 22 | 10.5 | 300*157*210 | |||
SCM-50 | 750 | 1 | 108 | 32 | 12.8 | 300*188*240 | |||
DK Seires
Model
| Power | Q.MAX (L/min) | H.MAX (m) | S.Head (m) | Speed (r.p.m) | Pipe Dia (Inch) | N.W (kg) | Packing size (mm) | |
W | HP | ||||||||
1DK-14 | 370 | 0.5 | 75 | 12 |
9 |
2850 | 1″* 1″ | 7.4 | 270*147*172 |
1DK-20 | 550 | 0.75 | 120 | 16 | 1″* 1″ | 10.9 | 395*165*190 | ||
1.5DK-20 | 750 | 1 | 200 | 16 | 1.5″* 1.5″ | 11.4 | 305*165*192 | ||
2DK-16 | 1100 | 1.5 | 420 | 16 | 2″* 2″ | 20 | 365*220*220 | ||
2DK-20 | 1500 | 2 | 420 | 20 | 2″* 2″ | 23 | 365*220*220 | ||
DTM Seires
Model
| Power | Q.MAX (L/min) | H.MAX (m) | S.Head (m) | Speed (r.p.m) | Pipe Dia (Inch) | N.W (kg) | Packing size (mm) | |
W | HP | ||||||||
PX-201 | 370 | 0.5 | 110 | 14 |
9 |
2850 | 1″* 1″ | 13 | 320*210*210
|
PX-203 | 550 | 0.75 | 180 | 15 | 1.5″* 1.5″ | 14 | |||
PX-204 | 750 | 1 | 200 | 16 | 1.5″* 1.5″ | 14.6 | |||
PX-205 | 1500 | 2 | 420 | 20 | 2″* 2″ | 23 | 395*220*220 | ||
PX-207 | 2200 | 3 | 700 | 20 | 3″* 3″ | 37 | 440*255*280 | ||
PX Seires
Model
| Power | Q.MAX (L/min) | H.MAX (m) | S.Head (m) | Speed (r.p.m) | Pipe Dia (Inch) | N.W (kg) | Packing size (mm) | |
W | HP | ||||||||
DTM-16 | 1100 | 1.5 | 300 | 16 |
9 |
2850 | 1″* 1″ | 20 | 340*210*250 |
DTM-20 | 1500 | 2 | 420 | 20 | 2″* 2″ | 22 | 410*220*275 | ||
CM-20 | 750 | 1 | 165 | 18 | 1.5″* 1.25″ | 14 | 310*175*225 | ||
CM-30 | 1500 | 2 | 420 | 20 | 2″* 2″ | 24 | 395*220*220 | ||
CM-40 | 2200 | 3 | 600 | 22 | 3” * 3” | 34 | 440*280*220 | ||
CM-50 | 3000 | 4 | 860 | 24 | 3″* 3″ | 40 | 420*320*240 | ||
110V,115V,127V,230V,240V,110/220V,50HZ/60HZ,380V 50HZ three-phase etc.Models are acceptable if request.
INSTALLATION AND APPLICATIONS
These pumps are suitable for pumping clean water and fluids which are not chemically aggressive to the pump components. They are extremely reliable,economical and simple to use,being particularly suitable for domestic applications such as the automatic distribution of water from small and medium-sized surge tanks, watering gardens,etc .These pumps should be installed in a covered area,protected against the weather. N.B.it is always advisable to install a foot valve or a non-return valve on the suction opening.
