Home > Products > Water Pumps > 600W Plastic Pump Body Clean Water Garden Pump
600W Plastic Pump Body Clean Water Garden Pump
                            US$ 38 - 58
                                                            / Piece


                                                100 Pieces(Min. Order)

                    - FUZHOU
 - T/T

You May Like
-


Stainless Steel Dirty Water Garden Submersible Pump
 -


Plastic Dirty Water Garden Submersible Pump
 -


Plastic Clean Water Garden Submersible Pump
 -


Stainless Steel Clean Water Garden Submersible Pump
 -


New Design Stainless Steel 400W~1100W Clean/Dirty Water Garden Submersible Pump
 -


New Design With CE Plastic/Stainless Steel 250W~1100W Garden Submersible Pump

Product Details
| Place of Origin | Fujian, China | Brand Name | OEM | |
| Model Number | CGP | Theory | Jet Pump | |
| Structure | Single-stage Pump | Usage | Water | |
| Power | Electric | Standard or Nonstandard | Standard | |
| Fuel | Other, CLEAN WATER | Pressure | High Pressure | |
| Application | Other, CLEAN WATER |
Product Description
600W Plastic Pump Body Clean Water Garden Pump
Pressure tank: 19L,24L
Pressure switch: 1-1.3KG
Pressure guage: MR/6
Brass connector: 5-way
 Suction lift up to 9 m
Fluid temperature up to + 60°C
Maximum ambient temperature +40°C

INSTALLATION AND APPLICATIONS
These pumps are suitable for handing clean water not containing abrasive particles and fluids which are not chemically aggressive to the pump components.
These pumps consist for DB series pump,pressure tank,pressure switch,pressure guages and brass connector.
They are extremely reliable, light, economic and simple to use, finding many uses in domestic applications, in particular the automatic distribution of water from surge tanks, watering gardens and for boosting insufficient mains water pressure.
These pumps should be installed in a covered area, protected against the weather.
They are extremely reliable, light, economic and simple to use, finding many uses in domestic applications, in particular the automatic distribution of water from surge tanks, watering gardens and for boosting insufficient mains water pressure.
These pumps should be installed in a covered area, protected against the weather.
PERFORMANCE
The wide range of pumps in the DB series satisfies the most various operating requirements with features such as:
high heads with respect to power requirements.
Stable operating curves, with small variations in delivery rates with respect to large variations in the pressure demand.
high tolerance of the presence of entrained air in the fluid to the pumped.
Suction capacity up to 9 meters.
Stable operating curves, with small variations in delivery rates with respect to large variations in the pressure demand.
high tolerance of the presence of entrained air in the fluid to the pumped.
Suction capacity up to 9 meters.
| AUTOJETL Series Self-Priming JET Pump | |||||||||
| Model | Power | Q.MAX | H.MAX | S.Head | Speed | Pipe Dia | N.W | Packing size | |
| W | HP | (L/min) | (m) | (m) | (r.p.m) | (Inch) | (kg) | (mm) | |
| AUTOJET-60L | 460 | 0.6 | 55 | 35 | 9 | 2850 | 1"*1" | 17.3 | 435*188*230 |
| AUTOJET-80L | 600 | 0.8 | 60 | 40 | 1"*1" | 18 | 435*188*230 | ||
| AUTOJET-100L | 750 | 1 | 60 | 45 | 1"*1" | 18.7 | 435*188*230 | ||
| AUTOJETP Series Self-Priming JET Pump | |||||||||
| Model | Power | Q.MAX | H.MAX | S.Head | Speed | Pipe Dia | N.W | Packing size | |
| W | HP | (L/min) | (m) | (m) | (r.p.m) | (Inch) | (kg) | (mm) | |
| AUTOJET-60P | 460 | 0.6 | 55 | 35 | 9 | 2850 | 1"*1" | 17.6 | 435*182*260 |
| AUTOJET-80P | 600 | 0.8 | 60 | 40 | 1"*1" | 18.3 | 435*182*260 | ||
| AUTOJET-100P | 750 | 1 | 60 | 45 | 1"*1" | 19 | 435*182*260 | ||
| AUTOJET-140P | 1100 | 1.5 | 60 | 65 | 1"*1" | 35 | 556*235*290 | ||
| AUTOJET-160P | 1500 | 2 | 65 | 70 | 1"*1" | 38 | 556*235*290 | ||
