AL/PL Blister-Carton Packaging Production Line
- 10 Set / Sets per Month
- SHANGHAI
- T/T D/P D/A Credit Card PayPal
You May Like
-
JDZ-260L Automatic High Speed Blister Cartoning Production Line
-
DPP88 Mini Auto Blister Packing Machine
-
DXDDC-10 Tea Bag Auto Packing Machine
-
YD-168 Automatic tea-bag inner and outer bag packing machine
-
YD-18I/ II Automatic tea-bag inner and outer bag packing machine
-
YD-11 Automatic Teabag Hang Thread & Label Packing Machine
Product Details
| Application | Beverage, Food, Medical | Packaging Type | Pouch | |
| Packaging Material | Wood | Automatic Grade | Automatic | |
| Driven Type | Electric | Voltage | 380V 50Hz 3phase | |
| Power | 5.5KW | Place of Origin | China | |
| Brand Name | SUNHANG | Model Number | AL/PL | |
| Weight | 1600 | Dimension(L*W*H) | 2900X7200X1550MM | |
| Certification | GMP |
Product Description
AL/PL Blister-Carton Packaging Production Line
SUMMARIZE
To decrease the cost and packing products cross pollution, our company develop these two machines in line.
The main part of this line is our DPB series blister packaging machines connecting the ANTZ series cartooning machines through conveyor device and the and controlled by PLC. t can make blister packing unqualified products rejection, leaflets folded and sealing carton.
This equipment suits to pack capsules, tablets and ampoules into AL/PVC or Paper/PVC blisters then connect with cartooning machine.
Note:we can manufacture the Filling Machine and Cartoning Machine in line according to customers’ requirements.
Aluminum Plastic Main Technical Parameter
Punching Frequency | 6~50cycles/min | |
Punching sheet | 4blisters/stroke | |
Adjustable Stroke | 40~160mm | |
Productivity | 1000-12000sheets/hour | |
Max Forming Area and Depth | 245×155×26mm | |
Total Power | 380V 50Hz 3phase 5.5Kw | |
Specificationa of Packing Material | Medical PVC | 250×0.25(0.15~0.50mm) |
PTP AL Foil | 250×0.02mm | |
Air-Consumption | ≥0.22m3/min | |
Pressure | 0.5~0.6MPa | |
Overall Dimension | 2900×7200×1550mm | |
Weight | 1600kg | |
Carton Main Technical Parameter
Electric power | AC220V phases and five-wires 50Hz total power 1.5kw |
Production capacity | Rotation speed 50-100b/min Speed of folding machine:50-80p/min |
Volume of consumption | 20m3/h(pressure 0.5-0.7Mpa) |
Leaflet | Quality requirement 50-65g/m2 |
Unfolded Leaflet Specifications(80-300)×(70-210)mm | |
Folded Leaflet Specifications(70-210)×(20-40)mm | |
Overall dimension(mm) | 2800×880×1800 |
Weight | Approximately1200kg |
