NJP-1200-1000-900A/B/C/D Fully Automatic Capsule Filling Machine
- shanghai
- T/T Credit Card PayPal
You May Like
Product Details
| Condition | New | Capacity | 72000capsules/hour | |
| Control Mode | Full Automatic | Place of Origin | China | |
| Brand Name | sunhang | Model Number | NJP-900/1000/1200NJP1500/2000A/B/C/D | |
| Dimension(L*W*H) | 1600X1000X2100mm | Weight | 1000KG | |
| Certification | GMP |
Product Description
Specifications
This Machine Conforms to GMP standard is suitable for filling Number 0 to Number 4 machine made capsulesNJP-1200-1000-900A/B/C/D Fully Automatic Capsule Filling Machine
Product Description:Proudcut Description
This model is an intermittent motion and hole plate type filling full automatic capsule filling equipment. It adopt optimization design for meeting the characteristics of chinese medicine and the requirement of GMP, it has the characteristics of compact mechanism, small volume, lower noise, precision filling dosage, multi-function, stably running etc. It can finish the following motion at the same time: capsule feeding, capsule separating, powder filling, capsule rejecting, capsule locking, finished capsule discharge and die hole cleaning etc. It is the most ideal hard capsule filling equipment for pharmaceutical and health food industry.
Technical Parameter:
Machine Model | NJP-900A/B/C/D | NJP-1000A/B/C/D | NJP-1200A/B/C/D |
Max. Output | 54000 Capsules/Hour | 60000 Capsules/Hour | 72000 Capsules/Hour |
Capsule Size | Suitable for filling capsule size 00#-5# Supro/safefy capsule size:A-E (need to exchange the spare parts/moulds accordingly) | ||
Dosage Type | Powder/Pellet/Tablet | ||
Power Supply | 380V 50Hz 2.5kw (Can be made according to the client’s voltage standard) | ||
Noise Index | < 75dBA | ||
Machine Size/N.W. | 1020mm×860mm×1970mm Net Weight:900KG | ||
Packing Size/G.W. | 1650mm×1000mm×2150mm Gross Weight:1000KG | ||
Remark:
Model A is common configuration, it adopts domestic cam graduation box, reducer and vacuum pump;Model B is high configuration, it adopts well-known brand cam graduation box, reducer and vacuum pump in the world. Model C is super configuration, it increase Siemens PLC & Human Machine Interface(LCD) control system on the base of Model B configuration; Model D increase the printer to print the production data and Omron optical fiber checking system on
the base of Model C configuration.
