YL Series Single-phase Two-value Capacitor Induction Motor

                                 YL series single-phase two-value capacitor induction motor

1. Model: YL series
2. Rated Voltage: 220V
3. Rated frequency: 50HZ, 60HZ
4. electric motor with competitive price

Advantages:

YL series single-phase dual-capacitor asynchronous motor is designed and manufactures in according with national standard, newly developed by our company with low noise, compact construction, light weight, easy maintenance etc. These motors are widely used on air compressors, pumps, fanx, refrigerators, medical instruments, small-size machines etc, especially for occasion where only single-phase power supply is available.

Operating conditions:

1. Ambient temperature: -15°C<q<40°C

2.Altitude: Not exceeding 1000 meters

3.Rated voltage: 220V

4.Rated frequency: 50HZ/60HZ

5.Duty/Rating: Continuous ( running )

6.Insulation class: Class B/F

7.Protection: IP44/IP54

8. Cooling method: IC0141

FUAN LIYUAN ELECTRICAL MACHINERY CO.LTD, professionally produces the motor, generator, water pump of different series, which have been sold to all the China and exported to more than 100 countries in America, Europe, Southeast Asia and so on, with the high quality and best prices, the products are warmly welcome by the clients from the home and abroad. The main products are as follows: Y, Y2, AEEF, Series three phase induction motor. YC, JY series heavy-duty single-phase induction motor. MY, MG, ML, MS series induction motor with the aluminum housings. YCG series induction motor with the steel-plate housings. ST, STC series generator , TZH series Compound Excitation generator. SFS, GFS series low noise diesel generating set. LY950...LY6500 series gasoline generator, and IDB, QB, JET... Series water pump .
