Charger Soshine H4 for 4x 18650, 26650 Rechargeable Batteries

FOB Price

US$ 16.00 - 16.00 / Piece

100 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Charger Soshine H4 for 4x18650, 26650 rechargeable batteries

Skype: shine

Measurements

The charger will charge with about 100mA from 0 volt.
At 0.6 volt regular charge current will be applied and a battery will be detected.
When a LiIon battery is detected the minimum voltage reading is 3.2V (With LiFePO4 it is 2.9V).
Maximum voltage reading for a LiIon is 4.2V (With LiFePO4 it is 3.6V).
When charging is done the meter is frozen.
If the voltage stays between 2.0 and 2.5 volt the charger will say "bat fail".
Below 2V the charger assumed NiMH and above 2.5V the charger assumes LiIon.
Charger will not officially restart if voltage drops, but charge current will increase.
Charge will restart charging after power loss, or battery insertion.
When not connected to power it will drain about 6mA from a LiIon battery and 1.6mA from a NiMH battery.
The chemistry and current settings are remembered, even if the power is removed.

Charger
Brand	Soshine
Model	H4
Quantity	1Piece
Color	Black
Material	ABS + PC
Charging Cell Type	LiFePO4 , Ni-MH , NiCd , Lithium Ion
Charging Battery Type	18350, 16340, 18500 , 18650 , AA , AAA , 10440 , 17670 , 26650
Rechargeable Battery Qty	4
Target Country & Region	Europe
Plug Specifications	EU Plug (2-Round-Pin Plug)
Built-in Protected Circuit	Yes
Input Voltage	AC 100~240V
Output Voltage	4.2 / 3.6 / 1.4V
Max. Output Current	4A
Fast Charging Function	Yes
LCD Screen	Yes
Auto Circuit Detection	Yes
Indicator	LCD
Over Voltage Protection	Yes
Short-Circuit Protection	Yes
Over-Charging Protection	Yes
Over-Discharging Protection	Yes
Other Features
Other Features	1.5" LCD screen, battery charger input: 12V 2000mA; Output: 1000mA x 4@ Lion 3.7V Battery; 1000mA x 4@ Ni-MH 1.2V Battery; 1000mA x 4@ LiFePO4 3.2V; Battery Charger mode: CC/CV(Li-ion Battery / LiFePO4 Battery)/DELTA V(Ni-MH Battery); Car charger: 12V

Dimensions & Weight
Dimensions	5.31 in x 3.86 in x 1.46 in (13.5 cm x 9.8 cm x 3.7 cm)
Weight	13.4 oz (380 g)

Packing List
1 x Universal Charger (H4) 1 x Car charger (140cm-cable) 1 x AC power Adapter (EU plug / 90cm-cable)

Detail Photos:

FAQ:

Q1: How do we place an order?

A1: Please kindly send us an email specifying the item, quantity, payment or other specification to place an order.

Q2: How do we make the payment?

A2: We accept Paypal, escrow ,Western Union, T/T. Please do only pay to the official account authorized by Soshine.

Q3: What's the delivery time?

A3: The delivery time is normally 2-7 working days after payment confirmed.

Q4: How would the goods be shipped?

A4: We ship via UPS,DHL ,FedEx, TNT normally, EMS also available.

Q5: What's the warranty for the purchased items?

A5: Warranty for chargers is a year (12 months),

Warranty for batteries is half a year (6 months).
