18650 Battery Charger/ Rechargeable Battery Charger/Soshine SC-S1 Mix III For18650/16340(RCR123)/14500, Etc

Bar Code: 6951151524256

Adapter:
- Input: AC adapter 100-240VAC,50/60Hz
- Output:12VDC - 1500mA
- DC car adapter :12V
Using an adapter that does not meet these specifications could damage the charger or the adaptor

Charger:
- Li-ion 18650 18500  - charging current =1000mA*1, 1000mA*2

- Li-ion 16340 18650 18500 10440 17335 RCR123- charging current =300mA*1, 300mA*2
- End-of-charge voltage detection assures the safe and full charge any time
- Short-circuit protection
- Over voltage cut-off protection ---  prevents damage to your battery due to over voltage(4.3V)
- Complete individual channels ------  convenience; prevent batteries charge each other
- Charge Method :CC/CV --------------charge battery fully and quickly
- Reverse polarity protection --------  prevent damage to your battery and charger
- Time control  -------------------------  4 individual clocks,after charge 8 hour, the power cut down
- Temperature control ----------------  temperature >60 degree, the power cut down

- Battery reset---------------------------make short circuit protection battery to reset

4 LED indicate:
Red on ------------------------------------Battery Charging

Green flash ------------------------------Charge 80%-90% complete
Green on ---------------------------------Charge 90%-100% complete
Turn off -----------------------------------Stand by without battery in compartment
                                                             Loose connections (replace battery);
                                                             Polarity reversed (load the battery into charger in right side)
                                                             Low voltage less than 2V
Red-Green flash (after 5min) ----------Non rechargeable Li-ion battery like Lithium,Ni-MH ,Ni-Cd, Alkaline
                                                             Li-ion battery--Low voltage between 2-3V
                                                            Temperature >60 degree

Instructions for use:

-Insert the rechargeable Li-ion battery into the battery compartment
-Make correct contact for polarity (+ and -) according to the sign in the battery compartment

When using AC adaptor:
Connect the supplied AC adaptors barrel plug into jack on the back of the charger. Plug the AC adaptor into any available 100-240VAC outlet.
