PVC waterproofing membrane
- 2000000 Square Meter / Square Meters per Month
- qingdao
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | hongyuan | |
| Model Number | HY |
Product Description
Specifications
PVC waterproofing membrane1)thickness: 1.2mm, 1.5mm, 2mm
2)colour: Gray, green, blue
3)length: 20m
4)width: 2.05m
PVC waterproofing membrane
Polyvinyl Chloride (PVC) waterproofing membrane is a kind of polymer compound waterproof membrane compound of polyvinyl chloride colophony, plasticizer, stabilizing agent, ultraviolet radiation(UV) resistance agent, all kinds of dyes and other agent.
1)thickness: 1.2mm, 1.5mm, 2mm
2)colour: Gray, green, blue
3)length: 20m
4)width: 2.05m
PVC membrane can be used for waterproofing on the steel roof, walking roof, planting roof, tunnel, basement. Etc.
PVC Waterproof membrane | ||||||||
No. | Item | L | N | W | ||||
I | II | I | II | I | II | |||
1 | Tensile strength N/cm ≥ | 100 | 160 | 8 | 12 | 100 | 160 | |
2 | fracture elongation %≥ | 150 | 200 | 200 | 200 | 150 | 200 | |
3 | Dimension Changing at heating %≤ | 1.5 | 1 | 3 | 2 | 1.5 | 1 | |
4 | Foldability at low temperature °C | -20 | -25 | -20 | -25 | -20 | -25 | |
5 | Water tightness | No leakage | No leakage | No Leakage | ||||
6 | Joint shear resistance (N/mm)≥ | 3 | 3 | 6 | ||||
7 | Thermal Ageing treatment | Appearance | no bubble | no bubble | no bubble | |||
Tensile strength changing rate % | ±25 | ±20 | ±25 | ±20 | ±25 | ±20 | ||
Breaking elongation changing rate% | ||||||||
8 | Chemical corrosion resistance | foldability at low temperature °C | -15 | -20 | -15 | -20 | -15 | -20 |
Tensile strength changing rate % | ±25 | ±20 | ±25 | ±20 | ±25 | ±20 | ||
Breaking elongation changing rate% | ||||||||
9 | Artificial climate accelerated aging | foldability at low temperature °C | -15 | -20 | -15 | -20 | -15 | -25 |
Tensile strength changing rate % | ±25 | ±20 | ±25 | ±20 | ±25 | ±20 | ||
Breaking elongation changing rate% | ||||||||
N1 | PVC membrane without compound layer for exposed | |||||||
N2 | PVC membrane without compound layer for non exposed | |||||||
L1 | PVC membrane with compound layer for exposed | |||||||
L2 | PVC membrane with compound layer for non exposed | |||||||
W1 | PVC reinforced membrane for exposed | |||||||
W2 | PVC reinforced membrane for non exposed | |||||||
