Automatic Mustard Oil Extraction Machine in Pakistan
- Qingdao Shanghai
- T/T L/C D/P D/A Credit Card
You May Like
-
China TOP3 Manufacturer Refined Rice Bran Oil Extraction Machine
-
China TOP3 Manufacturer Rice Bran Oil Extraction
-
Most Effective Castor Oil Extraction Machine
-
2016 Factory Price Automatic Soybean Oil Extraction Machine Quality Choice
-
Top Sale !! Cotton Seed Oil Extraction Mill With Fine Quality and Reasonable Price
-
Peanut Oil Extractor Machine
Product Details
| Condition | New | Usage | Other, mustard oil extraction machine | |
| Type | Other, Cold & Hot Pressing Machine | Automatic Grade | Automatic | |
| Production Capacity | 20-2000TPD | Place of Origin | Henan, China | |
| Brand Name | Huatai | Model Number | mustard oil extraction machine | |
| Voltage | 380V(or as your requirement), 380V(or as your requirement) | Power(W) | 50KW | |
| Dimension(L*W*H) | Standard | Weight | Standard | |
| Certification | CE/ISO, CE ISO | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Automatic mustard oil extraction machine in pakistan
1.More than 60 years cooking oil machine manufacturing experience
2.Have factory and professional engineers
3.Can Offer full production line, according to different oilseeds
4.Patents and CE,ISO,SGS
Capacity: 20T-2000T/D
Automatic mustard oil extraction machine in pakistan
As for oil extraction machine, that is using oil extraction method and choosing an organic solvent which candissolve oil, after contacting with pretreated oil--spray or immersion, so that oil can be extracted. As the boliling point of solvent and oil are different, after evaporation and stripping, the solvent are evaporating and we can get crude oil.
Oil extraction machine general flow charts
Solvent-- Extractor--Mixed oil -- 1st and 2nd evaporation -- Stripping tower -- Crude oil
Wet meal -- DTDC toaster -- Meal
Craft features of oil extraction machine
1.Adopting negative pressure evaporation can ensure excellent oil quality
2.Extraction system is highly adaptable and can adapt to different raw material
3.All equipment is provided with exhaust gas absorption systems with excellent absorption effect
4.Full energy-saving design utilizes heat energy for many times and saves steam consumption
Advantages:
Towline extractor, Rotocel extractor, loop extractor
Evaporation and steam stripping equipment
DTDC high efficient energy-saving toaster
The craft index for 20-200T/D oil extraction machine:
1.Solvent consumption: 2.5kg per ton raw material
2.Steam consumption: 250-300kg per ton raw material
3.Electricity consumption:12-19kw.h per ton raw material
4.Water consumption: 0.2m3 per ton raw material
5.Residual oil of meal: ≤0.5-1.5%
6.Residual solvent of meal: ≤500ppm(passing detonation test)
The craft index for 200-2000T/D oil extraction machine:
1. Solvent consumption: 1.5kg per ton raw material
2. Steam consumption: 200-250kg per ton raw material
3. Electricity consumption:7-9kw.h per ton raw material
4. Water consumption: 0.2m3 per ton raw material
5. Residual oil of meal: ≤0.5-1.5%
6. Residual solvent of meal: ≤500ppm(passing detonation test)

Country | Project Name | Raw material |
Bangladesh | 30T/D rice bran expanding and extraction , | Rice bran |
5T/D rice bran oil refining project | ||
Malaysia | 100T/D palm fruit oil refinery project | Palm fruit |
Sudan | The whole production line for | Peanuts |
30T/D peanuts oil making equipment | ||
Bolivia | 60T/D soybean oil refinery project | Soybean |
Indonesia | 30T/D copra oil extraction , and 20T/D copra oil refinery | Copra |
Kazakhstan | 3T/D cotten seeds oil refinery project | Cotten seeds |
Our company -- Henan Huatai Food & Oil machinery Engineering Co.,Ltd has been in the field of oil press machine for many years,are professional manufacturer in the oil machinery production field in China, Our products durable quality and high oil yield have win a good reputation at home and abroad.
Main Projects Scope:
30-5000T/D oilseeds pretreatment project
30-5000T/D oilseeds extraction project
5-1000T/D crude oil refining project
5-1000T/D crude oil fractionation project
Oil interesterification project
Oilseeds protein, phospholipid project
Natural pigment extraction project
Grain deep processing project
Typical Project:
30-1000T/D rice bran pretreatment, expanding, extraction project
30-600T/D rice bran oil refining project
150-1000T/D cottonseed dephenolizing protein
10-1000T/D palm fruit oil pressing project
10-500T/D Non acid method biodiesel production project
10-2000T/D corn deep processing project
Newest Technology:
Energy saving oil vacuum deodorization technology
Concentrated protein extraction technology
Mixed oil extraction technology
Mixed oil refining technology
Molecular distillation technology
Broken rice desaccharification technology
Continuous lignite extraction technology
Also offer single use mustard oil extraction machine
Contact us for more information !!
