Low Residual Rate Rice Bran Oil Extraction Plant From China for Selling

Oil production line including: Oil Pretreatment and Prepressing equipment, Oil Extraction equipment, and Oil Refinding equipment

Brief flow chart

Advantages of Oil extraction Plant

1.Adopting negative pressure evaporation can ensure excellent oil quality

2.Extraction system is highly adaptable and can adapt to different raw material

3.All equipment is provided with exhaust gas absorption systems with excellent absorption effect

4.Full energy-saving design utilizes heat energy for many times and saves steam consumption

Requirements for extraction material, steam, water, electricity etc

1.Moisture of extraction material: 5-8%

2.Temperature of extraction material: 50-55

3.Oil content of extraction material: 14-18%

4.Thickness of extraction cake: ≤13mm

5.Powder degree of extraction material: ≤15%(30 meshes)

6.Steam: ≥0.6Mpa

7.Solvent: national standard No.6 solvent oil

8.Powder electricity: 50hz 3x380v ±10%; lighting electricity:50hz 220v ±10%

9.Temperature of supplement water: ≤25  Hardness: ≤10

10.Volume of supplement water:1-2m3/t raw material

11.Temperature of recycle water: ≤32

Our company -- Henan Huatai Food & Oil machinery Engineering Co.,Ltd has been in the field of oil press machine for more than 60 years,are professional manufacturer in the oil machinery production field in China, Our products durable quality and high oil yield have win a good reputation at home and abroad.

1. Semi-automatic Screw oil press machine
2. Full-automatic Screw oil press machine
3. Hydraulic oil press machine( used for cold press)
4. Palm oil press machine
5. Mini cooking oil refining machine unit
6. Oil production line/plant
10T TO 5000T/D Oil pretreatment and prepressing equipment/project
20T TO 5000T/D Oil extraction equipment/project
5T TO 1000T/D crude oil refining equipment/project
