Automotive insulation
Negotiable
/ Meter
1000 Meters(Min.Order)
- 100000 Meter / Meters per Month
- Dalian
- T/T
You May Like
Product Details
| Place of Origin | Liaoning, China | Brand Name | UPM | |
| Model Number | A3 |
Product Description
Specifications
Automotive brake protective heat shrink tubeShrink Ratio: 1.5:1
Semi-rigid outer layer
Protection of brake line
Automotive brake protective heat shrink tube
A3 Brake / Fuel Line Protection Heat Shrinkable Tubing
Voltage Class 1kV Ideal for protection of metal line that are subject to bending and clamping
Dual wall Heat Shrinkable tubes specially designed for automotive market. Provide preventive protection against corrosion and protect against stone and gravel damage. The semi-rigid outer layer also prevent damage occurs during parts installation, clamping and servicing. The adhesive inner layer seal against moisture and will not separate from the substrate during bending operations.
Applications
Protection of brake line, fuel line, hydraulic line or other metal pipeline which is subject to bending or clamping operations during manufacturing, installation or operation
Features/Benefits
Shrink Ratio: 1.5:1
Semi-rigid outer layer for mechanical damage prevention
Adhesive inner layer, sealing against moisture and prevent corrosion
Easy installation, the adhesive layer will not separate from pipeline during bending process.
Temperature Range
Operating Temperature : -55 ~ 80 ºC
Shrink Temperature : 110 ºC
Color:Black
Product Code Cross References
Raychem/Tyco : AP2000
DSG Canusa : DERAY®MDKT
SUMITOM :O2
LG : GSHS-2690NW
Technical Details
| Test Item | Test Method | Typical Data |
| Tensile strength | ASTM D2671 | ≥ 18Mpa |
| Breakdown elongation | ASTM D2671 | ≥ 400% |
| Outer layer specific gravity | ASTM D792 | 1.0 |
| Tensile strength after aging | ASTM D2671 | ≥ 17Mpa |
| Breakdown elongation after aging | ASTM D2671 | ≥ 320% |
| Heat impact (200 for 4h) | ASTM D2671 | no drop no flow |
| Low temperature flexibility (-55 for 4h) | ASTM D2671 | no cracking |
| Volume Resistivity | ASTM D2671 | ≥ 1014Ω.cm |
| Dielectric strength | ASTM D2671 | ≥ 20kV/mm |
| Water absorption | ASTM D570 | ≤ 0.4% |
| Copper corrosion | ASTM D2671 | pass |
| Horizontal impact resistance (at -35) | ASTM D746 | no damage |
| Drop impact resistance (at -35) | ASTM D746 | no damage |
| Stress cracking resistance | ASTM D1693 Part 5.3.6 | no damage |
Product Selection
| Product Code | Wall thickness after free recovery(mm) | Adhesive layer thickness after free recovery(mm) | Standard Package (m/roll) |
| A3-Φ5.5/3.3 | 1.0±0.1 | 0.2 | 200 |
| A3-Φ6.5/4.7 | 1.0±0.1 | 0.2 | 200 |
| A3-Φ8.5/6.0 | 1.0±0.1 | 0.2 | 100 |
| A3-Φ11.0/7.0 | 1.0±0.1 | 0.2 | 100 |
| A3-Φ15/9.5 | 1.0±0.1 | 0.2 | 100 |
Ordering
When ordering this product, please specify 1) Product code 2) Quantity required in number of rolls
