REOO solar power junction box with easy installation
US$ 2.5 - 2.7
/ Piece
1 Piece(Min. Order)
- shanghai
- Credit Card
You May Like
-
High Quality Solar PV Junction Box Waterproof Solar Panel PV Junction Box
Quality Choice
-
2016 REOO 200-380W Waterproof IP67 Solar PV Junction Box
-
REOO solar China 4/6mm2 Solar Connectors Crimping Tools manufacturer
-
Free shipping Connector Solar PV cable cutter connector MC4 Solar Crimp Tool
-
NEW MC4 connector tool suitable for 2.5/4/6mm crimping tool
-
Special for MC3 and MC4 Crimping Tools from REOO solar
Product Details
| Place of Origin | China | Brand Name | REOO | |
| Model Number | PV-HF804 | Type | Other, Other, Junction Box |
Product Description
Solar Junction Box
Main Specility:
With the capacity of anti-aging and resistance to ultraviolet radiation on the outer cover;
To meet the using requirement under bad outdoor condition;
2-4plugs are required to internally installed at the end base;
Double connection of both inseting and tight-top style are applied for the connection cables.
Related Parameters
| Parameters | ||
| Electrical | Rated Current | 9A |
| Rated Voltage | 1000VCD(TUV) | |
| Contact Resistance | ≤5mΩ | |
| Security Level | Class Ⅱ | |
| Application Level | A | |
| Reverse Current Overload | 15A | |
| Mechanical Properities | ||
| Temperature | -40℃ to + 85℃ | |
| Cable Range: | 2.5mm2-4mm2 | |
| Degree of Protection | IP67 | |
| Flammability Rating | UL94-VO&UL94-5VA | |
| Material Properities | ||
| Testing Standards | EN50548/AI:2003 | |
| Dimensions | 155.5x135x23mm |
Detailed Images
