HDMI KVM Extender / Transmitter & Receiver
Product Details
| Brand Name | CHEERLINK | Model Number | DX312342 | |
| Place of Origin | Guangdong, China |
Product Description
HDMI KVM extender includes transmitter and reviver. Transmitter combines HDMI video, audio and control signals, and then transmits them through single CAT5e cable. Receiver gets these signals, separates signals and rebuilds video/audio, output through HDMI interface.
Connector | HDMI,3.5mm,Cat 6,Cat 5e |
Power Adapter | US Plug |
Power Supply | Input: 100~240V, 50/60Hz 0.25A, Output: 5V 1000mA. |
Certification | CE / FCC / RoHS |
Other Features | Power: <2.5W TX, <1.5W RX; Video bandwidth: maximum TMDS clock frequency 225MHz, 6.75Gbps; Resolution and Distance: 1080P 50M-Cat5e / 80M-CAT6; 720P/1080i 80M-Cat5e / 100M-CAT6; Audio format: 8-Channel, support Dolby TrueHD and DTS Master; TMDS input signal: 1.2V point to point; DDC input signal: 5V point to point; HD interface standard: HDMI 1.3 standard (HDMI 1.4 3D function), HDCP 1.2, support CEC, EDID; Support 3D signal, all 7 formats; UART date rate: Support 4800bps, 9600bps, 19200bps, 39400bps, 57600bps; Remote IR: 38khz; Temperature range: Operation 0-40'C, stock -20-60'C. |
