Home > Products > Hydraulic Cylinders > (best Quality ) Hydraulic Telescopic Cylinder for Tipper Truck/dump Truck/ Hydraulic Press Machine

(best Quality ) Hydraulic Telescopic Cylinder for Tipper Truck/dump Truck/ Hydraulic Press Machine

FOB Price

US$ 90 - 3,080 / Piece

1 Piece(Min. Order)

Port Tianjin

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Fittings		Model Number	YHC
Brand Name	YH		Place of Origin	Hebei, China

Product Description

Specifications

1.Max Bore:1200mm
2.Max Stroke:15000mm
3.Seal kits:Parker/Merkel Seal or as you required
4.customised as your requirements

Company Information

ISO9001:2008 certified
Complete CNC Machining capabilities
Bore size from 1 1/5" to 20" (30mm to 500mm)
Stroke lengths to 200'' (5000mm) or longer
Working pressures to 32Mpa
Up to 4 stage of multi stage hydraulic cylinder experience

Our Services

We have more than one decade experience in supplying custom hydraulic cylinders with provided drawings or samples, or if you could provide following specification:

diameter of bore & rod
stroke
mounting type
closed/open centers
working pressure
ports
seals
other requirement

Product Description

Model Number	Cylinder Capacity ton (kN)	Stroke (mm)	Collapsed Height A (mm)	Extended Height B (mm)	Outside Dia. D (mm)	Cylinder Bore Dia. E (mm)	Plunger Dia. F (mm)	Cylinder Effective Area (cm2)	Oil Capacity (cm3)	Weight (kg)
YH-50**	5 (45)	16	41	57	58***	28,7	25,4	6,5	10	1,0
YH -51	5 (45)	25	110	135	38	28,7	25,4	6,5	16	1,0
YH -53	5 (45)	76	165	241	38	28,7	25,4	6,5	50	1,5
yh-55*	5 (45)	127	215	342	38	28,7	25,4	6,5	83	1,9
YH-57	5 (45)	177	273	450	38	28,7	25,4	6,5	115	2,4
YH-59	5 (45)	232	323	555	38	28,7	25,4	6,5	151	2,8
YH-101	10 (101)	26	89	115	57	42,9	38,1	14,5	38	1,8
YH-102*	10 (101)	54	121	175	57	42,9	38,1	14,5	78	2,3
YH-104	10 (101)	105	171	276	57	42,9	38,1	14,5	152	3,3
YH-106*	10 (101)	156	247	403	57	42,9	38,1	14,5	226	4,4
YH-108	10 (101)	203	298	501	57	42,9	38,1	14,5	294	5,4
YH-1010*	10 (101)	257	349	606	57	42,9	38,1	14,5	373	6,4
YH-1012	10 (101)	304	400	704	57	42,9	38,1	14,5	441	6,8
YH-1014	10 (101)	356	450	806	57	42,9	38,1	14,5	516	8,2
YH-151	15 (142)	25	124	149	69	50,8	41,4	20,3	51	3,3
YH-152	15 (142)	51	149	200	69	50,8	41,4	20,3	104	4,1
YH-154*	15 (142)	101	200	301	69	50,8	41,4	20,3	205	5,0
YH-156*	15 (142)	152	271	423	69	50,8	41,4	20,3	308	6,8
YH-158	15 (142)	203	322	525	69	50,8	41,4	20,3	411	8,2
YH-1510	15 (142)	254	373	627	69	50,8	41,4	20,3	516	9,5
YH-1512	15 (142)	305	423	728	69	50,8	41,4	20,3	619	10,9
YH-1514	15 (142)	356	474	830	69	50,8	41,4	20,3	723	11,8
YH-251	25 (232)	26	139	165	85	65,0	57,2	33,2	86	5,9
YH-252*	25 (232)	50	165	215	85	65,0	57,2	33,2	166	6,4
YH-254*	25 (232)	102	215	317	85	65,0	57,2	33,2	339	8,2
YH-256*	25 (232)	158	273	431	85	65,0	57,2	33,2	525	10,0
YH-258	25 (232)	210	323	533	85	65,0	57,2	33,2	697	12,2
YH-2510	25 (232)	261	374	635	85	65,0	57,2	33,2	867	14,1
HY-2512	25 (232)	311	425	736	85	65,0	57,2	33,2	1033	16,3
YH-2514*	25 (232)	362	476	838	85	65,0	57,2	33,2	1202	17,7
YH-308	30(295)	209	387	596	101	73,2	57,2	42,1	880	18,1
YH-502	50 (498)	51	176	227	127	95,2	79,5	71,2	362	15,0
YH-504	50 (498)	101	227	328	127	95,2	79,5	71,2	719	19,1
YH-506*	50 (498)	159	282	441	127	95,2	79,5	71,2	1131	23,1
YH-5013	50 (498)	337	460	797	127	95,2	79,5	71,2	2399	37,6
YH-756	75 (718)	156	285	441	146	114,3	95,2	102,6	1601	29,5
YH-7513	75 (718)	333	492	825	146	114,3	95,2	102,6	3417	59,0
YH-1006	95 (933)	168	357	525	177	130,3	104,9	133,3	2239	59,0
YH-10010	95 (933)	260	449	709	177	130,3	104,9	133,3	3466	72,6
