Home > Products > New Products > 25w 12v universal atx switch power supply manufacture
25w 12v universal atx switch power supply manufacture
- 4000 Piece / Pieces per Month
- shenzhen
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | SANPU | |
| Model Number | PS25-W1V12 | Output Power | 1 - 50W | |
| Output Type | Single | Input Voltage | Other, 85-264VAC | |
| Output Voltage | 12V | Output Frequency | 47-63HZ | |
| Output Current | 0-2.1A |
Product Description
Specifications
atx switch power supply1.2years warranty
2.built-in EMI fiter with tiny ripple
3.CE ROHS supported
4.life span is 50000H
Specification:
1. atx switch power supply
2.Constant voltage output
3.Output current accuracy:5%
4.2 years warranty
5.100% full load burn-in test tion
6.Power efficiency:>85%
7.Power factor (PF):>0.95
8.Ambient temperature:-20°C—60°C
9.Ambient humidity:80% non-condensing
10.Mean Time Between Failure:>30000h
11.High performance, High Efficiency
12.High reliability, High power
13.Products with the anti-jamming, greatly reduce the LED light failure
tions
Input specification | AC input voltage range | 85---264VAC | |||
Input frequency | 47-63Hz | ||||
AC inrush current | 30A/230VAC | ||||
Output specification | Output voltage can be adjusted | ±10% | |||
Start-up time | leq1S(input230V,Io=100%) | ||||
keep time | more than or equal to 20mS (input230V,Io=100%) | ||||
Voltage regulation | (Full load) leq0.5% | ||||
Protection function | Overload protection | 105% - 135% rated power, automatic recovery | |||
Over-voltage protection | 105% - 135% of the rated voltage | ||||
Insulation intensity | Input---output | 1500VAC/1min | |||
Input---ground | 1500VAC/1min | ||||
Input---ground | 500VAC/1min | ||||
Safety standards | According with GB4943, UL60950-1,EN60950-1 standards. | ||||
E M C standards | According with GB9254, EN55022 class A EN61347-2-13:2008 standards | ||||
Environmental | working temperature | - 20 ° ~ 60 ° c / 20% ~ 90% RH (no frost) | |||
Storage temperature | –40°C~85°C/10%~95%RH | ||||
height above sea level | leq2000M | ||||
Structure | Size(mm) | 85(L)*58(W)*33(H) | |||
Cooling method | Cooling method | Natural cooling air convection | |||
Weight | 0.15KG/PCS, 100pcs/15kg | ||||
Product Type Table | |||||
Product model | output specification | Error, range | efficiency | ||
PS25-W1V12 | 12V | 0-2.1A | ±1%, 100mV | 84% | |
PS25-W1V15 | 15V | 0-1.7A | ±1%, 100mV | 85% | |
PS25-W1V24 | 24V | 0-1.1A | ±1%, 150mV | 86% | |
Promise:
1. Your inquiry related to our products or prices will be replied in 24hours;
2. Well-trained and experienced staffs to answer all your enquires in fluent English;
3. Any your customized demand we can help you to design and put into product;
4. As professional LED power supply Manufacturer, we must give you the lowest price with high quality.
