Manufacturer Supply OEM 75Ohm 0.81mm Copper/CCS 90% Braiding Rg59 +2 Power Cable

FOB Price

USD $0.01 - $0.05 / Kilometer

30 Kilometers(Min.Order)

Supply Ability 20000 Box / Boxes per Month
Port Shanghai/Ningbo
Payment TermsT/T D/P D/A

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China	Brand Name	DSC
Model Number	Rg59	Type	Coaxial
Number of Conductors	1

Product Description

Manufacturer Supply OEM 75Ohm 0.81mm Copper/CCS 90% Braiding Rg59 +2 Power Cable
Specification:

Center Conductor:	0.58+0.01mm CCS21%/ BC or 0.81mm,0.64mm
Dielectric:	3.7+0.05mm Solid PE
Bradi Coverage:	35%-95% BC/CCA
Jacket:	6.10+0.05mm PVC /PE

2C Power wire:
0.37mmX7 CCA or BC+1.8 Black/red PVC or UTP Cat5e ,or 4 Core Telephone cable

2. Rg59-2C Coaxial Cable Electrical Properties

Impedance:	75+3 Ohm
Capacitance:	50+3pF/km
Velocity of Propagation:	85%
Conductor resistance Max:	Inner:16.8 ohms/km Outer:26 ohms/km
Return Loss:	20dB min (5-2150MHz)gbgfbbgfb

Application
Used as a distribution cable for indoor CATV,CCTV systems and as a connection cable for satellite systems where lower attenuation required.
