120T Good Vertical Rotary Table Injection Molding Machine
USD $1,500 - $80,000
/ Set
1 Set(Min.Order)
- 3 Set / Sets per Month
- Zhongshan
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
160T Good Vertical Injection Rotary Table Molding Machine
-
200T Good Vertical Injection Rotary Table Molding Machine
-
55T Good Tie-barless injection molding machine C55R
-
85T Good Tie-barless injection molding machine C85SD
-
85T Good Tie-barless injection molding machine C85
-
55T Good Tie-barless injection molding machine C55
Product Details
| Condition | New | Type | Preform Injection | |
| Style | Vertical | Brand Name | Qianke | |
| Model Number | V120R2 | Place of Origin | Guangdong, China | |
| Plastic Type | Thermoplastic | Automatic | Yes | |
| Injection Weight | 151-236g | Injection Rate | 112(172)mm/s | |
| Clamping Force | 120Tf, 30-500 Ton | Opening Stroke | 280mm | |
| Certification | CE | After-sales Service Provided | Overseas service center available |
Product Description
Specifications
1.Clamping force 35-500tons2.Vertical clamping,Vertical injection,easy to insert
3.Famous brand in each parts.
4.Yuken,Omron
1,Specifications
| Unit | V120R2 | |||||
| Injection Unit | Screw Diameter | mm | 36 | 40 | 45 | |
| Theoretical Injection Volume | cm3 | 162 | 201 | 254 | ||
| Injection Weight(PS) | g(oz) | 151(5.3) | 187(6.6) | 236(8.3) | ||
| Max.Injection Pressure | Mpa(kgf/cm2) | 222(2268) | 180(1838) | 142(1452) | ||
| Injection Rate | cm3/s | 114 | 140 | 178 | ||
| Injection Speed | mm/s | 112(172) | ||||
| Screw Speed Rotation | r.p.m | 0-300 | ||||
| Nozzle Out From Platens | mm | ≥45 | ||||
| Clamping Unit | Clamping Force | KN(tf) | 1176(120) | |||
| Clamping Stroke | mm | 280 | ||||
| Min.Mold Thickness | mm | 280(380) | ||||
| Max.Opening | mm | 560(660) | ||||
| Distance Between Tie Bars | mm | |||||
| Max.Mould Size | mm | 400*400 | ||||
| Platen/Slide Size | mm | 1170 | ||||
| Ejector Distance | mm | 110 | ||||
| Ejector Force | KN(tf) | 45(4.6) | ||||
| Others | System Pressure | Mpa(kgf/cm2) | 13.7(140) | |||
| Oil Tank Capacity | L | 410 | ||||
| Electric Power | KW(HP) | 18.5(25) | ||||
| Heater Power | KW | 10.7 | ||||
| Machine Dimensions | L*W | mm | 2470*1950 | |||
| H | mm | 3200(4040) | ||||
| Machine Weight | tf | 6.4 | ||||
2,Pictures
1.Clamping force 35-500tons
2.Vertical clamping,Vertical injection,easy to insert
3.Famous brand in each parts.
4.Yuken valves ,Omron PLC,Siemens Motor.
