Bosch Protocol Convert Pelco and Molynx Protocol Converter
US$ 70 - 120
/ Piece
1 Piece(Min. Order)
- Shenzhen
- T/T Money Gram Credit Card
You May Like
-
AD Protocol Convert Pelco or Molynx Protocol Converter
-
Project Necessary Product Pelco Protocol Converter
-
2 Axis Keyboard Controller for Dahua or Hikvision DVR
-
Copper Video Distributor for CCTV System With 16CH Input and 48 CH Output for Security Camera and DVR Quality Choice
-
Copper Video Distributor for CCTV System With 8CH Input And32 CH Output for Security Camera and DVR
-
3 Axis Keyboard Controller for Dahua or Hikvision DVR
Product Details
| Place of Origin | Guangdong, China | Brand Name | Aliviz | |
| Model Number | AS-4010PH |
Product Description
Specifications
Protocol converter mainly used in the field of convert different protocol and baud rate between Matrix ,keyboard controller.Protocol converter AS-4010PH mainly used in the field of convert different protocol and baud rate between Matrix ,keyboard controller ,DVR or other host machine and PTZ, receiver or other terminal device . When DVR and matrix control the terminal device, the protocol converter box can play the function of connection and convert protocol. Protocol converter box support multi-protocol and baud rate which it is the necessary equipment in the large system of surveillance project.
1. Technical Parameters
Adaptor | AC220V or AC110V |
Power supply | 3W |
In /Communication | RS485 or Manchester |
Out/Communication | RS485 |
Work Temperature | -400C~+700C |
Size(mm) | 160 x 66 x 27 |
Weight(Kg) | 0.69 |
Matrix Control Terminal Device throught converter DVR control terminal Device throught converter
2. Multi-Protocol Support
Input Protocol :
PHILIPS,BOSCH,UNIVISION
Output Protocol :
PELCOD,PELCOP,VICON,KALATEL,CS-850/860,MOLYNX,SAMSUNG,AD,SAE,B01/TD500PIH1016
3. Multi-Baud Rate Support
1200,2400,4800,9600
