Home > Products > BTS Passive Components > 15dB 800-2500MHz Directional Coupler
15dB 800-2500MHz Directional Coupler
USD $3.5 - $6.5
/ Piece
50 Pieces(Min.Order)
- Shanghai
- T/T Credit Card PayPal
You May Like
-
10dB 800-2500MHz Directional Coupler
-
rf coaxial fixed attenuator n male to n female connector 2 watt
-
rf coaxial fixed attenuator N male to N female connector 5 Watt
-
30 Watt N Type Coaxial Dummy Load (Terminator )
-
RF coaxial fixed attenuator n connector 10 w
-
50 Watt N Type Coaxial Dummy Load (Terminator )
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Four Star | |
| Model Number | FSDC-0825-15NF |
Product Description
Specifications
1. Wide Frequency Range2. Low VSWR
3.Low IM 3rd.
4. Fast Delivery
| Product Name | 800-2500MHz, 200 watts, N-female, 10/15/20/30 dB Directional Coupler | |||
| Model No. | FSDC-0825-10NF | FSDC-0825-15NF | FSDC-0825-20NF | FSDC-0825-30NF |
| Frequency(MHz) | 800-2500 | |||
| Insertion Loss(dB) | ≤0.8 | ≤0.5 | ≤0.40 | ≤0.30 |
| Coupling (dB) | 10 ± 1.0 | 15 ± 1.2 | 20 ± 1.30 | 30± 1.5 |
| Isolation(dB) | >23 | |||
| VSWR | ≤1.25:1 | |||
| Power Capacity(W) | 200 | |||
| Peak Power | 1KW | |||
| Impedance(ohm) | 50 | |||
| RF Connector | N-female Connector(Tri-metal Plating) | |||
| Intermodulation 3rd | ≤ -120 dBc@2×20W | |||
| Surface Colour | Black-plated | |||
| Operating Temp(deg) | -35~+70 | |||
| Housing Material | Aluminum | |||
| Relative Humidity | 5%-95% | |||
| Application | Indoor | |||
| Weight(kg) | 0.23 | |||
