Fiber Metal Laser Machine With Carbon Steel, Stainless Steel, Mild Steel, Alloy Steel
- China port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Fiber Laser Engraving Machine Price With Max. Cutting Speed 15m/min
-
Fiber Laser Cutter With Carbon Steel Stainless Steel, Mild Steel, Alloy Steel, Spring Steel, Aluminium
-
Ultra-thin Cnc Glass Cutting Machine for Phone Screen Protective Glass
-
Automatic Cnc Glass Cutting Machine for 3-19mm Thickness Glass
-
Cnc Glass Machining Center for Cut,drilling,edging 2mm Glass
-
Ultra-thin Cnc Glass Cutting Machine
Product Details
| Condition | New | Laser Type | Fiber Laser | |
| Applicable Material | Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood | Cutting Thickness | 0.2-8mm | |
| Cutting Area | 1300x2500mm | Cutting Speed | 0-1000mm/min | |
| CNC or Not | Yes | Cooling Mode | Water Cooling | |
| Control Software | LEETRO,RD | Graphic Format Supported | AI, BMP, DST, DWG, DXF, DXP, LAS, PLT | |
| Place of Origin | Shandong, China | Brand Name | PENN | |
| Model Number | PC-1325 | Certification | CE | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
fiber metal laser machine with carbon steel, stainless steel, mild steel, alloy steel
1) Cooling type Water-cooled fiber laser machine
2) Cutting precision 0.04 fiber laser machine
3) Continuous Working Time 24 hours fiber laser machine
4) Table Size 1300*2500mm fiber laser machine
Features
1. Compare with the plasma cutting, it has the high precision cutting for different kinds
of metal materials, like cutting stainless steel, carbon steel, alloy steel, spring steel, aluminum,
copper, silver, titanium and other metal materials below 6 mm.
2. Compare with the NC, which can cut any complicated process and shape.No noise and no
need to open any moulds at all.
3. Compare with linear cutting, which has much faster speed,100 times higher than it.
4. Double lead screw to drive, Small heat affected zone, good dimension stability. Flat and
handsome laser-slotted, without later process
5. High performance/price ratio: the price is only 1/8 of the similar CO2 laser cutting machine
and 2/5 of the equivalent NC Punch
6. Low use cost: only USD2 per hour which is 1/8-1/10 of the similar CO2 laser cutting
machine (USD22-USD35 per hour)
7. Low follow-up maintenance cost: only 1/10-1/15 of the similar CO2 laser cutting machine
and 1/3-1/4 the equivalent NC Punch
8. Steady performance: as a mature laser apparatus, the fiber laser cutting machine is
suitable for most metal manufacturing and processing industry.
Model: | PC-1325F | PC -1530F |
Working size: | 1300*2500MM | 1500mm×3000mm |
Cutting thickness: | 0.1mm-8mm/ | |
Max. output power: | 500W/1000W | |
Medium of Laser | Fiber | |
Laser wavelength: | 1064nm | |
Pulse frequency: | 1--300HZ | |
Min. linewidth: | 0.12mm | |
Electrical source: | 380V/50HZ/100A
| |
Cutting precision | ≤±0.04
| |
Supported format | Plt, Dxf, AI, Dst etc
| |
Continuous Working Time
| 24 hours | |
Machinel weight: | 3000kg
| |
Cooling way | water-cooling | |
Blowing way | Oxygen, Compressed air or Nitrogen | |
Max. cutting speed: | 15m/min (According to material and thickenss) | |
Other machines
Dear Sir or Madam:Do you want to know more
details or price?
Do you want to see the video of the machining
process?
Ok,please contact me.We will be waiting for your call or letter!
