Aluminum CNC Profile Machining Center With X-axis Stroke 5000 mm
- China port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
China Jinan Cnc Machining Center for UPVC Profile
-
Jinan 4 Axis Profile Cnc Machining Center for Curtain Wall PC-4000
-
China Jinan 4 Axis Profile Cnc Machining Center With Z-axis Stroke 200mm
-
Jinan 4 Axis Cnc Profile Machining Center With Spindle Power 5.5kw
-
4 Axis Cnc Aluminum Profile Machining Center
-
4 Axis Cnc UPVC Profile Maching Center With Working Pressure 0.6~0.8MPa
Product Details
| Condition | New | Place of Origin | Shandong, China | |
| Brand Name | PENN | Model Number | PC-5000 | |
| Voltage | AC380V | Rated Power | 7.5kw | |
| Dimension(L*W*H) | 5100x1420x1750mm | Weight | 3000kg | |
| Certification | C1 | Warranty | one year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
aluminum CNC profile machining center with X-axis stroke 5000 mm
1) Spindle Power 5.5kW
2) 3000kg
3) Working Pressure 0.6~0.8MPa
4) Total Power 7.5kW
1.Using advanced industrial CNC systems, friendly human-machine interface,device operation is simple
2.Suitable for aluminum alloy, aluminum and wood composite profile, profiles and other light alloys of copper, as well as the u-PVC profile processing
3.Bed made of high strength steel welded structure, completed after thermal aging treatment of machining in one clamping
4.Adopts imported high precision linear guideways, ball screws, gear racks and servo motor, ensuring smooth motion, positioning and processing of high precision
5.High-quality imported high speed spindle ensure stability, stability of rotation noise, cutting ability
X-axis stroke | 3000/4000/5000mm | Y-axis stroke | 300mm |
X-axis feed rate | 0~60m/min | Y-axis feed rate | 0~48m/min |
X-axis positioning accuracy | ±0.05mm | Y-axis positioning accuracy | ±0.05mm |
Z-axis stroke | 200mm | Repeat location accuracy | ±0.02mm |
Z-axis feed rate | 0~20m/min | Roughness | Ra 6.3 um |
Z-axis positioning accuracy | ±0.02mm | Spindle Power | 5.5kW |
Power Specification | 380V/50Hz/60HZ | Spindle Speed | 0~24000rpm |
Total Power of Machine | 7.5kW | Working Pressure | 0.6~0.8MPa |
Machine Size | 5100x1420x1750mm | Weight | 3000kg |
