LCCS-040T342 40.8w Linkcom Led power Supply/CONSTANT CURRENT/CE TUV

FOB Price

Negotiable / Piece

50 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

1,Linkcom LED Power
2,TUV CB
3,IP67,constant current 3400mA
4,40.8W (With PFC)

FEATURES

Suitable for Hi-Power LED Lighting Applications.

Universal AC input / Full range

Constant Voltage & Current limit Protection OVP; OTP and Short-Current Protection

High Operating ambient Temp: -20°C~+60°C

Design refer to EN 61347-2-13

Meet with CE EN55015

Comply with indoor/outdoor waterproof(IP67)

Power Factor : >0.95@115VAC / Full Load>0.9@230VAC / Full Load

Electrical Specifications @25°C
Model		LCCS-040T342		LCCS-040T172		LCCS-040T112
Output	DC Voltage	9 ~ 12		18~ 24		28 ~ 36
	Rated current	3.4A ± 3%		1.7A ± 3%		1.1A ± 4%
	Rated power	40.8W		40.8W		39.6W
	Protection	CV ; CC ; OVP ; OTP
Input	Voltage range	100~240Vac full range
	Frequency range	47~63Hz
	Efficiency (Typ.)	81%	83%		83%
	AC current	100Vac<0.5A 240Vac<0.3A	100Vac<0.55A 240Vac<0.3A		100Vac<0.5A 240Vac<0.3A
	Inrush current	50A/230Vac cold start
	Leakage current	0.75mA/132Vac/60Hz
Environment	Operating ambient Temp.	-20°C~+60°C
	Operating relative Hum.	10%~+90%
	Storage ambient Temp.	-40°C~+80°C
	Storage relative Hum.	10%~+95%
Others	MTBF	100000 hrs/25°C
	Safety & EMC	EN61347-2-13 & EN55015
	RoHS	YES	YES		YES
	Dimension(mm) LWH	957032
