Brohawk Cultivator
- Mumbai
- T/T L/C D/P D/A
You May Like
Product Details
| Condition | New | Type | Farm Cultivator | |
| Power Type | Diesel | Certification | ISO 9001:2000 | |
| Use | Cultivation | Place of Origin | Punjab, India | |
| Brand Name | Brohawk | Model Number | BCM- 180,230, & 280 |
Product Description
- Suitable for use in stone and root obstructed soil.
- It is designed for toughest operations.
- Used for loosening and aerating soil to a depth of nine inches.
- Prepares seed beds quickly and economically.
- When one tine strikes a hidden object, the other continue to work at the correct depth.
- Spring loaded assemblies derive their strength from heavy-duty angles, which once fixed to the immensely strong main frame cannot move or strain out of position.
CODE | 5 TINE BC-230 | 7 TINE BC-230 | 9 TINE BC-230 | 11 TINE BC-230 | 13 TINE BC-280 | 13 TINE BC-280 | 15 TINE BC-280 |
Angle (Channel) | 65 x 8 mm | 65 x 8 mm | 65 x 8 mm | 65 x 8 mm | 75 x 40 mm | 75 x 40 mm Foldable | 75 x 40 mm Foldable |
Spring | 10 mm WD, 50 mm OD 28.5 Coils | 10 mm WD, 50 mm OD 28.5 Coils | 10 mm WD, 50 mm OD 28.5 Coils | 10 mm WD, 50 mm OD 28.5 Coils | 10 mm WD, 50 mm OD 28.5 Coils | 10 mm WD, 50 mm OD 28.5 Coils | 10 mm WD, 50 mm OD 28.5 Coils |
Tine (forged) | 50 x 20 mm | 50 x 20 mm | 50 x 20 mm | 50 x 20 mm | 50 x 20 mm | 50 x 20 mm | 50 x 20 mm |
Pairs (Flat) | 50x8 mm | 50x8 mm | 50x8 mm | 50x8 mm | 50x8 mm | 50x8 mm | 50x8 mm |
Anchor Pin | 22 mm | 22 mm | 22 mm | 22 mm | 22 mm | 22 mm | 22 mm |
Nuts | High Tensile | High Tensile | High Tensile | High Tensile | High Tensile | High Tensile | High Tensile |
Frame Bolt | 1/2 x 1-1/4 (High Tensile) | 1/2 x 1-1/4 (High Tensile) | 1/2 x 1-1/4 (High Tensile) | 1/2 x 1-1/4 (High Tensile) | 1/2 x 1-1/4 (High Tensile) | 1/2 x 1-1/4 (High Tensile) | 1/2 x 1-1/4 (High Tensile) |
Tine Bolt | 5/8 x 2” (High Tensile) | 5/8 x 2” (High Tensile) | 5/8 x 2” (High Tensile) | 5/8 x 2” (High Tensile) | 5/8 x 2” (High Tensile) | 5/8 x 2” (High Tensile) | 5/8 x 2” (High Tensile) |
Linkage | 50 x 12 mm (rear) 50 x 12 (front) | 50 x 12 mm(rear) 50 x 12 (front) | 75 x 12 mm (rear) 50 x 12 (front) | 75 x 12 mm (rear) 50 x 12 (front) | 75 x 12 mm (rear) 50 x 12 (front) | 75 x 12 mm (rear) 50 x 12 (Front) | 75 x 12 mm (rear) 50 x 12 (front) |
Shovel | 8 mm En-45 | 8 mm En-45 | 8 mm En-45 | 8 mm En-45 | 8 mm En-45 | 8 mm En-45 | 8 mm En-45 |
Length | 1160 mm | 1670 mm | 2150 mm | 2440 mm | 2920 mm | 2950 mm | 3210 mm |
Width | 850 mm | 850 mm | 850 mm | 850 mm | 850 mm | 850 mm | 850 mm |
Height | 585 mm | 585 mm | 585 mm | 585 mm | 585 mm | 585 mm | 585 mm |
Tiller Pin | 2 mm | 22 mm | 22 mm | 25 mm | 25 mm | 25 mm | 25 mm |
Weight | 120 kg | 145 kg | 200 kg | 240 kg | 253 kg | 450 kg | 500 kg |
