Home > Products > Cultivator > Rotary Cultivator
Rotary Cultivator
US$ 120 - 1,000
/ Piece
25 Pieces(Min. Order)
- Mumbai
- T/T L/C D/P D/A
You May Like
Product Details
| Brand Name | Brohawk | Model Number | BC-23 |
Product Description
7 Tine Cultivator
- Suitable for use in stone and root obstructed soil.
- It is designed for toughest operations.
- Used for loosening and aerating soil to a depth of nine inches.
- Prepares seed beds quickly and economically.
- When one tine strikes a hidden object, the other continue to work at the correct depth.
- Spring loaded assemblies derive their strength from heavy-duty angles, which once fixed to the immensely strong main frame cannot move or strain out of position.
Specification:
Code | 7 Tine |
Frame (Channle) | 75 x 40 mm |
Spring | 10 mm WD, 50 mm OD 28.5 Coils |
Tine (forged) | 50 x 25 mm |
Pairs (angle) | 65x65x6 mm |
Anchor Pin | 22 mm |
Nuts | High Tensile |
Frame Bolt | M 12 x 35 (High Tensile) |
Tine Boltm | 18 x 65 mm (High Tensile) |
Linkage 3 Point | 50 x 12 mm(rear) 50 x 12 (front) |
Shovel | 8 mm En-45 |
Length | 1560 mm |
Width | 850 mm |
Height | 585 mm |
Tiller Pin | 25 mm |
Weight | 240 kg |
