mining surveying equipment, total station

FOB Price

US$ 2,800 - 3,000 / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Beijing, China		Brand Name	Topcon
Model Number	GTS-102N

1.three language optional:english, portuguese, spanish.
con workmanship made in china.
3.On-board program, 24,000 storage

topographic survey

Model Name		GTS-102N
Telescope	Length	150 Millimeters
	Objective Lens Diameter	45mm (EDM: 50mm)
	Magnification	30x
	Image	Erect
	Field of View	1°30'
	Resolving Power	3.0"
	Min. Focus Distance	1.3m
Measuring Range	1 Prism	6500 ft, 2000 meters
	3 Prism	8800 ft, 2700 meters
Measuring Accuracy	Prism Mode	±(2mm + 2ppm x D)m.s.e. fine, N/A
	Measuring Time	1mm: 1.2sec. (Initial 4sec.) fine, 0.2sec. (Initial 3sec.) coarse, N/A
Angle Measurement	Method	Absolute Reading
	Detection	2 Horizontal, 1 Vertical
	Minimum Reading	N/A, 1/5 mgon
Tilt Correction	Type	Single Axis
	Method	Liquid surface reflective profile sensor reading type
	Compensating Range	±3'
	Correction Unit	1 arc sec, N/A
Computer Unit	Display	2 screen, dot matrix graphic LCD display
Power	approximate battery life	9 including distance measurement, 40 Angle measurement only
