Clap Switches Automobile Relay Electrical Bimetal Contact Rivets ISO9001 Approved
- 45000000 Piece / Pieces per Month
- Wenzhou Ningbo Shanghai
- T/T Credit Card
You May Like
-
Micro Electrical Contacts Point Bimetal Material Rivets
-
Hot Sale Electrical Bimetal Rivets Silver Contact
-
RoHS Approved Manufacture Contact Point For Motorcycle
-
RoHS Approved AgCdO10 bimetal contact rivet for Relay and Switches
-
High quality Electrical bimetal rivets with RoHS approved
-
Bimetallic Electrical Silver Contact For LCD Display Push Button Switch
Product Details
| Place of Origin | Zhejiang, China | Brand Name | SAIJIN | |
| Model Number | Silver Electrical Contacts |
Product Description
Clap Switches Automobile Relay Electrical Bimetal Contact Rivets ISO9001 Approved
15-year Experience In Producing Silver Contacts
Relay Electrical Contacts overview:
The material of composite rivet's working layer is more flexible to choose than the solid precious metal rivet's, even though the precious alloy material has excellent electrical contact property. Rivet contact is suitable for the continuous automatic production of riveting and processing. It doesn't other processing technique(such as electroplating, welding, etc). So, it not only simplified the manufacturing process of contact component, improve the productivity and lower the cost, but also increase the assembling precision and reliability of the component.
Relay Electrical Contacts SPECIFICATION:
Items | Limit Deviation | Basic Dimension | ||||||||||
Head Diameter/mm | ±0.1 | 2.5 | 3 | 3.5 | 4 | 4.5 | 5 | 5.5 | 6 | 6.5 | 7 | 8 |
Head Thickness/mm |
±0.05 | 0.6 0.8 1.0 | 0.8 1.0 1.2 | 1.0 1.2 1.5 | 1.0, 1.2 1.5, 2.0 |
1.2, 1.5, 2.0 | ||||||
Head Layer/mm | S<0.4±0.060 S>0.4±0.060 |
0.3-0.4 |
0.35-0.50 |
0.40-0.60 |
0.50-0.70 | |||||||
Shank Diameter/mm | -0.02 -0.10 | 1.2
1.5 |
1.5 | 1.5
2.0 |
2.0 | 2.0
2.5 |
2.5 | 2.5
3.0 |
3.0 | 3.0
3.5 |
3.5 |
4.0 |
Shank Length/mm | +0.150 | 1-2.0 | 1-3.0 | |||||||||
Spheric Radius/mm | R<6±1 R>6±2 | 4 6 | 6 8 | 8 10 | 10 15 | 15 20 | 20 25 | |||||
Demoulding Angle | ±2 | 9,10,11,12 | ||||||||||
Relay Silver Contacts MAIN MATERIAL:
Ag/Cu, AgCdO/Cu, FAg/Cu, AgSnO2 , AgSnO2InO3/Cu, etc
Relay Silver Contacts CHARACTERISTIC:
- Silver rivet and Ag/Cu bimetal rivet contact:Pure silver has a high level of electrical and thermal conductivity, good plasticity and arc corrosion resistance, as well as a very low contact resistance.
- AgCu rivet contact:This contact has good electrical conductivity and its surface is not liable to oxidization.
- AgNi/Cu bimetal rivet contact:In low voltage engineering, this contact is widely used in AC switches as an electrical contact.
- AgCdO/Cu bimetal rivet contact:This contact includes AgCdO10, AgCdO12, AgCdO15, and this kind of electrical contact has one of the most important materials in silver - metal oxide contact material.
- AgZnO rivet and AgZnO/Cu bimetal rivet contact:The oxide of this contactor is more thermally stable than CdO.
- AgSnO2 and AgSnO2 In2O3 and bimetal rivet contact:AgSnO2 and AgSnO2In2O3 are the ideal environment-protecting materials for substituting AgCdO.
Silver Relay Contacts APPLICATION:
Mainly used in various switches, push button switches, rotary switches, limited switches, rocker switches, clocks, relays, contactors, miniature and small switches and temperature controllers.
If you want to inquiry please send the email to me with the drawings.
Drawings sample:
RIVET TYPE SILVER ALLOY CONTACTS LABELED DIAGRAM
D=silver contacts the head diameter (mm)
d=silver contacts the foot diameter(mm)
H=silver contacts the head thickness(mm)
L=length of silver contacts foot(mm)
h=silver head joints the thickness of silver recovery (mm)
θ =silver contacts ejection head angle(º)
R=Silver contacts at the top of arc degree(cm)
Trade terms:
1) Payment: T/T, western Union or Paypal
2) Delivery: 3-7 work days for sample, 12-15 work days for products
3) Port: Wenzhou/Ningbo/Shenzhen/shanghai
4) Logo/shipping marks: According to your requirements
5) Packaging: inner with vacuum plastic bag, external with carton
6) Shipping: By Express (EMS, DHL, UPS, ARAMEX), By Air or By Sea
Silver Relay Contacts PACKING:
Our LOCATION:
Bimetal silver contact cold heading machines. cold heading machines draft:
Bimetal silver contact Automotive Electro pulsing Machine to make mould :
Our Service:
1) You inquiry will be replied in 24hours
2) Well-trained and experienced staffs to answer all your enquires in fluent English
3) OEM & ODM
4) Protect your sales area, ideas of design and all your private information
- Customized sizes and materials are welcome
- OEM orders are welcome
FREE SAMPLE can be sent for your evaluation!
Samples policy:
-1. We accept sample order for testing our quality.
-2. Sample charged will be higher than our offer, negotiability!
-3. Charge sample offered depends on customer’s design
-4. Shipping cost need to pay by customers
-5. Customer’s express courier account is acceptable
-6. Without courier account ,we will ship by DHL, FedEx, UPS or TNT
-7. Lead time would be up to the quantity, usually 2-5 work days
Note: This sample charge is for the first deal only and will be deducted in your future formal orders.
Production Workshop:
