Low Price 10A 20A 30A PWM Street Light Solar Controller

FOB Price

US$ 7 - 13 / Piece

10 Pieces(Min. Order)

Port guangzhou
Payment TermsCredit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	CAP
Model Number	10a 20a 30a	Application	Solar System Controller
Rated Voltage	12V	Maximum Current	30a

Product Description

Specifications

Intelligent control is realized by using microprocessor and ddedicated control calculation.
Photocontrol and time control

12v/24v 10A 20A 30A LED PWM Solar Controller Street Light solar controller

Photocontrol and time control

Product View:

Solar controller for PV systems, coordination of solar panels, batteries and work load, is a very important photovoltaic system component. It makes the whole solar system work efficiently and safely. Solar street light controller is mainly used for domestic, commercial, factory, transport, pastoral areas, communication and other photovoltaic power systems.

Technical specification:

Model	01	02	03
Fixed charging current	10A	20A	30A
Rated load electric current	10A	20A	30A
System Voltage	12V,24V,36V,48V
Over-load protection	1.3 multiple Nominal current,60 seconds or 1.6 Multiple Nominal current,5 seconds,Over-load protection movement
Short circuit protection	50A	100A	150A
Transient current	25A	50A	75A
No-load loss	<5mA
Charge return route pressure drop	≤0.26V
Electric discharge return route pressure drop	≤0.15V
Overpressure protection	17V/12V;34/24V
Operating temperature	Technical grade:-35C to +55C
Promotion charging voltage	14.6V;×2/24V;(Maintenance time:10min)
Straight charging voltage	14.4V;×2/24V;(Maintenance time:10min)
Floating	13.6V;×2/24V;
Charge returns voltage	13.2V;×2/24V;
Temperature compensation	-5mV/C/2V
Undervoltage voltage	12.0V;×2/24V;
Has put the voltage	11.2V;×2/24V;
Has put the returns voltage	12.6V;×2/24V;
Control mode	The way of PWM Pulse-duration modulation
Size	140×90.5×28.5mm
Weight	220g
