Product Details
| Place of Origin | Germany | Model Number | 1XP8012-10 | |
| Usage | Speed Sensor | Theory | Optical Sensor | |
| Output | Digital Sensor |
Product Description
new rotary encoder model 1XP8012-10/1024 original 1XP8012-10-1024
IXP8012-10/1024 (TTL) made in Germany
Supply : +10 V to +30 V (HTL)
Current input without load: 200mA ;
Maximum load current per output:100mA;
Resolution, Pulses per revolution:1024 P/R ;
Pulse offset between the two outputs:90 ± 20%
Output amplitude: U High> UB-3.5V, U Low< 3V;
Minimum edge interval: 0.8uS at 160 KHz;
Edge sttepness(without load or cable): t+, t-<200 ns
Maximum frequency : 160 kHz ;
Maximum speed : 9000 /MIN; 9000 rpm
Temperature range -20 C to 100C;
Degree of protection: IP66;
Maximum radial cantilever force: 60N;
Maximum axial force: 40N;
Termination system: 12-PIN ; 12-way plug (socket supplied)
IXP8012-10/1024;
CSA approved encoder; UL certificated rotary encoder;
Weight: 0.5 Kg with package
German encoders in stock:
1XP8012-10/1024
1XP8012-11/2048
1XP8022-10/1024
1XP8022-11/2048
1XP8032-10/1024
