original 1XP8001-1-1024 new rotary encoder 1XP8001-1/1024
USD $432.10 - $432.10
/ Piece
1 Piece(Min.Order)
- 123 Piece / Pieces per Month
- Shanghai
- Credit Card
You May Like
-
original 1XP8001-1/2048 new rotary encoder model 1XP8001-1-2048
-
original 1XP8001-2-1024 new rotary encoder model 1XP8001-2/1024
-
new rotary encoder model 1XP8001-2/2048 original 1XP8001-2/2048
-
new rotary encoder model 1XP8012-10/1024 original 1XP8012-10-1024
-
new rotary encoder model 1XP8012-11/2048 original 1XP8012-11
-
new rotary encoder model 1XP8022-10/1024 original 1XP8022-10
Product Details
| Place of Origin | Germany | Model Number | 1XP8001-1/1024 | |
| Usage | Speed Sensor | Theory | Optical Sensor | |
| Output | Digital Sensor |
Product Description
original 1XP8001-1-1024 new rotary encoder 1XP8001-1/1024
lXP8001-1/1024 (HTL) made in Germany
Supply : +10 V to +30 V (HTL)
Current input without load: 200mA ;
Maximum load current per output:100mA;
Resolution, Pulses per revolution:1024 ;
Pulse offset between the two outputs:90 ± 20%
Output amplitude: U High> UB-3.5V, U Low< 3V;
Minimum edge interval: 0.8uS at 160 KHz;
Edge sttepness(without load or cable): t+, t-<200 ns
Maximum frequency : 160 kHz ;
Maximum speed : 9000 /MIN; 9000 rpm
Temperature range -20 C to 100C;
Degree of protection: IP66;
Maximum radial cantilever force: 60N;
Maximum axial force: 40N;
Termination system: 12-PIN ; 12-way plug (socket supplied)
IXP8001-1/1024;
CSA; UL;
Weight: 0.5 Kg with package
