15 Ton per day continuous rubber powder de-vulcanizing machine Desulphurizing machine
- QINGDAO
- T/T
You May Like
-
Rubber Refining Mill Main Machine used in Rubber Reclaimed Line
-
Patent and Well-sealed Silicone Rubber Mixer
-
Reclaimed Rubber Line/Rubber Internal Banbury Mixer
-
Rubber Machine Manufacturer in Qingdao of China/Rubber calendeing line
-
22'' two roll double shaft two roll rubber mixing mill
-
Rubber Machine Manufacturer in Qingdao of China/Rubber recycled Machine
Product Details
| Condition | New | Type | Vulcanizer | |
| Place of Origin | Shandong, China | Brand Name | HUATUO | |
| Model Number | XLB | Voltage | 380 V | |
| Power(W) | 22 KW | Dimension(L*W*H) | ACCORDING TO DIFFERENT MODEL | |
| Weight | 20 Tons | Certification | CE,SGS AS WELL AS ISO9001:2008 | |
| Warranty | 3 YEARS GUARANTEE | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
15 Ton per day continuous rubber powder de-vulcanizing machine Desulphurizing machine
1. Environmental protection and energy saving: no waste water, waste gas, using circulating water cooling. Plasticizing powder
consumption per ton of 100-170KW;
2. Safety: atmospheric pressure conditions of production, the operator feeding on the ground;
3. Easy operation: PLC control, man-machine interface operation;
4. Each module has a real-time measurement value of feeding, discharging, water temperature into the PLC control system;
5. Each module individually sets temperature, temperature error within ± 1 °C;
6.Using electromagnetic heating or heat conduction oil furnace in two ways;
7.Products do not stick on conveyer, no need to clean up, with production while cleaning function;
8.Process parameters of memory function, memory function formula, etc;
9.Easy installation and maintenance, safe and reliable and remote maintenance.
| Model | MS R15 | ||
| Production Capacity(T/24H) | 10~16 | ||
| Heating Method | Electromagnetic/ Heat Conducting Oil | ||
| Power(Kw) | 192 | ||
| Operating Temperature(°C) | 200~320 | ||
| Dimensions(mm) | 9600X6000X6000 | ||
| Weight(KG) | 24600 |
Qingdao HuaTuo Machinery Co., Ltd. is one of the important backbone enterprises in rubber machinery industry in China and is the member of Shandong machinery union company.
Our company owns powerful technical strength, advanced techniques, the best design and a strict quality guarantee system, and owns a high reputation in Chinese rubber machinery industry.
The main products are plate vulcanizing presses, open rubber mixing mills, Banbury intensive kneaders, extruders and rubber and reclaimed rubber machinery.
The products have been sold to more than 20 provinces and cities in China and have been exported to more than 10 countries and areas. All of the products are designed visually by three-dimension CAD design, quickly built module, limited element analysis, analogue action and interfering inspection.
The combination of three-dimension CAD system and Internet guarantees the synchronization with international advanced technology. The combination of three-dimension CAD and CNC numeral process center realizes the transit from traditional manufacture to modern three-dimension manufacture. At the same time, our company keeps good contact with several universities and research institutes.
Our company takes "To live by quality, To develop by reputation, To innovate by science and technology, To keep improving all the time" as management idea, and insists on the principle of "Quality is the first, Reputation is first, Client is the first". We will provide you with the best service.
