Automatic lubricate Well Mixing Rubber Kneader
- Qingdao Port
- T/T Credit Card
You May Like
-
XSM series Rubber Internal Banbury Mixer
-
Reclaimed Rubber Line/XKJ-450 Rubber Sheet Refiner
-
Less Enviroment Pollution Reclaimed Rubber Producing Machinery
-
Three Machine One Line Less Pollution Reclaimed Rubber Machinery
-
Rubber Sheet Film Cooling Line 8-12fans
-
Machine Manufacturer of Rubber Internal Banbury Mixer
Product Details
| Condition | New | Type | Rubber Kneader | |
| Place of Origin | Shandong, China | Brand Name | CN Huatuo | |
| Model Number | XSN35-XSN110 | Voltage | 380v or different | |
| Power(W) | 15KW to 160KW | Dimension(L*W*H) | model varies | |
| Weight | 6.5-16tons | Certification | CE and ISO | |
| Warranty | one year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Rubber kneaderback door feeding way
well sealed,no leakage of material
auto lubricate pump
chamber and rotors chromed
Well- sealed Rubber banbury mixer
1.Application of Banbury Rubber Kneader/kneader machine
Banbury Rubber Kneader used for rubber or plastic plasticizing and mixing or rubber and plastic blends.
2.Advantage of Banbury Rubber Kneader/kneader machine
1)high efficiency. Rubber or plastic material will plasticized or mixed with high productivity in a closed ,pressurized and controlled temperature environment.
2)energy saving. the capacity is 6~8 times compared with open mill under the same condition of power level.
3)eco-friendly.the special dust sealing unit provide reliable sealing
4)durable in use. The banbury rotor adopt 42Crmo material and plated hard chorme made it wear-resisting greatly so does the speed reduce and gearbox;
5)excellent cooling/heating effect .all the parts connect with material adopt jacket structure and can adapt different requirements for the rubber or plastic mixing process.
6)high mixing quality.optimization of the parameters such as the helical angle of rotor wings and the wing overlap length brings about homogenous distribution of the stock.
7)PLC control.
nique parameter for rubber kneader
Type Name | X(S)N -35/30 | X(S)N- 55/30 | X(S)N 75-30 | X(S)N 110/30 | |
Mixing volume of mixing cabinet |
35 | 55 | 75 | 110 | |
(r/min) Frontback rotor friction ration | 1.22 | 1:1.22 | 1:1.22 | 1:1.22 | |
Power of main motor | 55 | 75 | 110 | 160 | |
Turning-over angle | 1400 | 1400 | 1400 | 1400 | |
Working pressure of compressed air | 8 | 8 | 8 | 8 | |
Overall | Length | 3200 | 3750 | 3760 | 3930 |
dimension | Width | 1900 | 1950 | 2143 | 3000 |
(mm) | High | 2950 | 3050 | 3050 | 3660 |
Weight(kg) | 6500 | 7800 | 10000 | 16000 | |
4.pictures as follows:
This is the automatic lubricate pump
