High Capacity Long Roll Four Roll Rubber Calendering Machine
- Qingdao Port
- T/T Credit Card
You May Like
-
High Technology Three Shaft Rubber Calender
-
Vertical Pattern Three Roll Rubber Calender
-
Rubber Machine Manufacturer in Qingdao of China/Rubber Calender
-
Best Quality Rubber plastic calender machine high efficiency four roll calender machine xy-4s 900*3400
-
Best Quality Rubber plastic calender machine best sale four roll calender machine xy-4f 360*31120
-
Best Quality Rubber plastic calender machine three roll rubber calender for rubber and plastic industry
Product Details
| Condition | New | Type | Rubber Calender | |
| Place of Origin | Shandong, China | Brand Name | CN HUATUO | |
| Model Number | XY3I630 | Voltage | 380V or different | |
| Power(W) | 7.5KW | Dimension(L*W*H) | Models varied | |
| Weight | 2.5tons | Certification | CE and ISO | |
| Warranty | lifetime warranty | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
High Capacity Long Roll Four Roll Rubber Calendering Machine
Advantage
1. The 3 or 4 rolls are separately driven by DC motors, which allow a wide rang of speed adjustment. The rotating speed ratio of the 4 rolls can be freely adjusted. The rolls are equipped with preloading device and bearings lubrication failure alarm device, as well as nip display and speed display.
2. The rolls are made of chilled cast iron with vanadium and titanium alloys. The roll face is hard and anti-wear. To heat up or cool down, the rolls are either circumferentially drilled or centrally bored so as to make temperature well proportioned on the roll surface.
3. The rolls are arranged in S form. Roll 1# and roll 4# have roll cambers that can eliminate bending impact on rolls during working process. Thus, it is possible to make products with same thickness along axial direction.
4. The transmission system adopts a hard facing gear reducer, which has a compacted structure with higher transmission efficiency, lower noise and longer service life.
5. The machine is equipped with emergency device. When an emergent accident occurs, the calendar will be immediately stopped to open the roll space so as to protect the operator and equipment. PLC program controller is used in electric system.
Specifications:
Model Item | XY-3I 630 XY3L630 XY-3F 630 | XY-3I 1120A XY-3F 1120A XY-3L 1120A | XY-3I 1400 | XY-3I 1500 | XY-3I 1730 | XY-3I 2130 | XY-3I 2430 | |
| Roall dia | mm | 230 | 360 | 400 | 450 | 610 | 710 | 810 |
| Roll working length | mm | 630 | 1120 | 1400 | 1500 | 1730 | 2130 | 2430 |
| Middle-roll linear speed | r/min | 0.8-8 | 3-21.06 | 3-26.39 | 2.62-26.2 | 5.4-54 | 8-50 | 2-20 |
| Adjusting nip range | mm | 0-7 | 0-10 | 0-10 | 0-6 | 0-20 | 0-20 | 0.5-25 |
| Min.Calendering product thickness | mm | 0.2 | 0.2 | 0.2 | 0.2 | 0.15 | 0.15 | 0.5 |
| Calendering product width | kg | 100-500 | 500-920 | 1200 | 1400 | 1500 | 1900 | 2150 |
| Motor power | KW | 7.5 | 45 | 55 | 75 | 132 | 185 | 220 |
| Qverall dimensions | L mm | 3168 | 5550 | 6500 | 7420 | 7010 | 7650 | 9300 |
| W mm | 890 | 1640 | 1500 | 2200 | 3950 | 4560 | 3150 | |
| H mm | 1830 | 2120 | 2440 | 2900 | 3730 | 4080 | 5200 | |
| About weight | t | ~2.6 | ~11 | ~22 | ~26 | ~52 | ~67 | ~94 |
