Typically YS-600 YS Series Dead Weight Tester Calibration Machine
- Any port of China
- T/T L/C D/P D/A Credit Card
You May Like
-
Digital Piston Pressure Gauge Dead Weight Tester With Newest Technology
-
YS MODEL Piston Vacuum Pressure Gauge From Manufacturer YUNYI
-
KY-0.25 or 0.6 Double Piston Vacuum Gauges DWT
-
Y-series Floating-ball Pressure Gauge
-
Pressure Calibration Device Floating-ball Pressure Gauge FROM YUNYI
-
Floating-ball Pressure Gage With Best Price and Best Quality
Product Details
| Place of Origin | Shaanxi, China | Brand Name | Yunyi | |
| Model Number | YS series | Power | Hydraulic | |
| Usage | Balancing Machine |
Standard export package
Product Description
Typically YS-60 YS series dead weight tester calibration machine
dead weight tester (DWT) is a calibration standard which uses a piston cylinder on which a load is placed to make an equilibrium with
an applied pressure underneath the piston.Deadweight testers are so called primary standards which means that the pressure
measured by a deadweight tester is defined through other quantities; Length, mass and time.
Typically deadweight testers are used in calibration laboratories to calibrate pressure transfer standards like electronic pressure
measuring devices.
Purpose:
YS-6 Deadweight Tester. Pressure Range 5.8 - 87psi. Accuracy: 0.015% or 0.020% of reading.
YS-60 Deadweight Tester. Pressure Range 14.5 - 870 psi. Accuracy: 0.015% or 0.020% of reading.
YS600 Deadweight Tester. Pressure Range 145 - 8700 psi. Accuracy: 0.015% or 0.020% of reading
Specifications:
| Model | YS-6 | YS-60 | YS-250 | YS-600 | |||||
| Measure Range | bar | 0.4-6 | 1-60 | 5-250 | 10-600 | ||||
| Accuracy | % | 0.02 or 0.05 | |||||||
| Nominal Area of Piston | cm2 | 1 | 0.5 | 0.2 | 0.1 | ||||
| Carrier and Piston | Nominal Mass | kg | 0.4 | 0.5 | 1 | 1 | |||
| Produced Pressure | bar | 0.4 | 1 | 5 | 10 | ||||
| Supplied Weights | Nominal Mass | kg | 0.10.5 | 0.52.5 | 15 | 15 | |||
| Produced Pressure | bar | 0.10.5 | 15 | 525 | 1050 | ||||
| Quantity Block | pcs | 610 | 411 | 49 | 411 | ||||
| Pressure Connection | M 20×1.5 | ||||||||
| Working Medium | Transformer Oil (viscosity 9~12 centistokes at 20i), or Medical Castor Oil (aciditymg KOH/g) | ||||||||
| Dimensions | mm | 630×382×593 | |||||||
| Weight | kg | 20+5.6 | 26+29.5 | 26+49 | 26+59 | ||||
Company Profile
Xian Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer, Mr Tian has more than 30 years experience on this area, and he is one of the engineers who introduced the Rosemount technology. We are specialized in developing pressure transmitter, etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
