2/3" Format C-mount 1.0x Magnifying WD 65mm Telecentric Lens

FOB Price

US$ 1600.00 - 1800.00 / Cubic Inch

1 Cubic Inch(Min. Order)

Port Shanghai
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shanghai, China	Brand Name	AZURE
Model Number	AZURE-6515TSMH	Material	Glass
Usage	Optical	Structure	Other
Shape	Cylindrical

Product Description

SPECIFICATIONS

Working Distance :	65mm
Magnification :	1.5x
Resolution:	6.06μm
Format :	2/3"
Mount:	C
NA:	0.048
Effective Fno:	15.5
Field Range:	4.3×3.2mm
Depth of Field :	0.56mm
TV Distortion :	0.0015%
Dimension :	20x 89.4mm
Weight:

DIMENSIONS

MTF CURVES

1)Brilliant Technology is dedicated to being the leading provider of optical components and integrated optical inspection devices with high standard quality control. This goal will be achieved through our focus on the raw material selection, manufacturing process inspection, sampling,finalization and transportation monitoring.

2) During the manufacturing and sampling procedures, precious optical devices shall be used on the optical parameter detection such as surface irregularity, surface scratch,refractive index, coating and etc.

3) Not only optical components were strictly selected, but also the integrated devices. Every module will be under a series of spec run before releasing itself. Evaluation report comes along with the in-house test for the insurance of each devices’ regular working.
