Home > Products > Narrow aisle forklift > VNA forklift(TFB model)
VNA forklift(TFB model)
- Shanghai
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Anhui, China | |
| Brand Name | MIMA | Model Number | TFB15-50 | |
| Type | Powered Pallet Truck | Power Souce | AC Motor | |
| Rated Loading Capacity | 1500kg | Max. Lifting Height | 7200mm | |
| Min. Lifting Height | 3000mm | Fork Length | 1070mm | |
| Fork Width | 100mm | Overall Dimensions | 2680x1225x2120mm | |
| Certification | CE,SGS,ISO | After-sales Service Provided | Overseas third-party support available |
Product Description
Description:
AC Driving system, hydraulic steering;
Maximised Storage Capacities
Reduced handling times
Reduced costs
Less damage to product or property
TFB 4-direction reach truck with 4 direction changing and moving;
Rated load capacity: 2500kg;
Max lift height: 7200mm.
The user-friendly display allows you to tare off containers up to 100% of the scale range or you can input the known tare weight of a loaded.
Made stronger than the original truck.
All our weighing machines are made using high quality load cells that have a very good repeatability.
Description | TFB15-50 |
Rated Capacity (KG) | 1500 |
Operate Type | Stand-on |
Max. Lifting Height (MM) | 5000 |
Max Travel Speed km/h-laden/unladen | 7.5/8.5 |
Load center MM | 500 |
Fork Dimensions- L/W/T---mm | 1070*100*35 |
Lifting Speed (MM/S)-laden/unladen | 117/243 |
Side-travel Speed -km/h | 5 |
Overall Length (MM) | 2393 |
Overall Width (MM) | 1682 |
Height-Overhead guard--mm | 2320 |
Height---Mast Lowered(MM) | 2344 |
Height-Mast Extended w/Load-Backrest -mm | 5885 |
Height--Free Lift--mm | 1740 |
Tilt Angle----Upward/Downward--deg. | 3/5 |
Fork Spread Range(MM) | 247-780 |
Reach Stroke | 570 |
Min Ground Clearance--mm | 80 |
Wheel Type | Polyurethane Solid Tyre |
Driving Wheel (MM) | Φ343×108 |
Balance Wheel (MM) | Φ180×76 |
Front Wheel (MM) | Φ267×114 |
Battery V/AH- | 48V /300 AH |
Service Brake | Electromagnetic |
Parking Brake | Electromagnetic |
Charger-Intelligent | 48V /40 A |
Driving Motor (KW) | 5.5 (AC) |
Lifting Motor (KW) | 6.3 |
