Forklift training TFB
USD $5,000 - $40,000
/ Unit
1 Unit(Min.Order)
- 300 Unit / Units per Month
- SHANGHAI
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Anhui, China | |
| Brand Name | MIMA | Model Number | TFB | |
| Type | Powered Pallet Truck | Power Souce | AC Motor | |
| Rated Loading Capacity | 2500kg | Max. Lifting Height | 7200mm | |
| Min. Lifting Height | 2500mm | Fork Length | 1070mm | |
| Fork Width | 100mm | Overall Dimensions | 2393*1682*2320mm | |
| Certification | SGS | After-sales Service Provided | Overseas third-party support available |
Product Description
Specifications
forklift training,TFBTravel in 4 direction;with high-power battery;
AC Drive Motir, Load capacity:2500kg,lift height:7200
forklift training,TFB series;
4-directional forklift;AC Driving system, hydraulic steering;
Product Description
1. 1.TFB model are designed to trackle the problem of handling long load, Lumber,drywall,fiberboard,furniture,pipe,steel and other big & long loas, now you can move more easily and reduce storage space with TFB four-directional forklift;
2. The movement can be forward,backward and side ways in both directions. Unlike the typical forklift truck, TFB can allow you to creat narrower aisles, denser storage and handle long loads faster and more easily;
3. With 2500kg rated capacity,7200mm lift height,The drive wheel' and high mast' display make it smoothest and easiest to use in the business;
Model No. | TFB15 | TFB25 | ||
| Standard | Power Type | Battery | Battery | |
| Operate Type | Stand-on | Stand-on | ||
| Rated Capacity | Q(kg) | 1500 | 2500 | |
| Load center | C(mm) | 500 | 500 | |
| T y r e | Wheel Type | Polyurethane Solid Tyre | ||
| Front Wheel | mm | Φ267×114 | Φ267×114 | |
| Driving Wheel | mm | Φ343×108 | Φ380×165 | |
| Balance Wheel | mm | Φ180×76 | Φ204×76 | |
| Tyres No. -front/Driving/swivel caster | 2/ 1X / 2 | 2 / 1X / 2 | ||
| D i m e n s i o n | Fork Tilt Angle----Upward/Downward--deg. | α/β(º) | 3/5 | 3/5 |
| Height-Overhead guard--mm | h5(mm) | 2320 | 2320 | |
| Height-Pedal to Overhead guard | h6(mm) | 1888 | 1879 | |
| Min Ground Clearance | h7(mm) | 69 | 74 | |
| Overall Length | 11(mm) | 2354 | 2482 | |
| Reach Stroke | 12(mm) | 560 | 685 | |
| Wheel Base | y(mm) | 1335 | 1700 | |
| Front Overhang | x(mm) | 227 | 162 | |
| Overall Width | b1/b2(mm) | 1514 | 1688 | |
| Fork Dimensions | mm | 1070*100*35 | 1070*100*45 | |
| Width across forks | b5(mm) | 220-662 | 247-780 | |
| Trurning radius | Wa(mm) | 1587 | 1979 | |
| F u n c t i o n | Travel Speed -laden/unladen | km/h | 7.5/8.5 | 7.8/9.0 |
| Max. Gradeability -laden/unladen | % | ≤10 | ≤10 | |
| P o w e r | Drive Motor type | AC | AC | |
| Driving Motor (S2 60) | kw | 5.5 | 5.5 | |
| Lift motor type | DC | DC | ||
| Lift Motor (S3 15%) | kw | 6.3 | 7.5 | |
| Battery V/AH | V/AH | 48/300 | 48/400 | |
| Weight | Battery | kg | 486 | 650 |
| Service Weight | kg | 2370 | 2960 | |
| Steering | Steering type | Full hydraulic | Full hydraulic | |
| Parking Brake | Electromagnetic | Electromagnetic | ||
| Parking Operation type | Releasing braking | Releasing braking | ||
| Service Brake-Operation type | Releasing braking | Releasing braking | ||
| Other | Battery change | side loading | side loading | |
