Home > Products > Narrow aisle forklift > china forklift TC
china forklift TC
- 20 Unit / Units per Month
- SHANGHAI
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Anhui, China | |
| Brand Name | MIMA | Model Number | TC | |
| Type | Powered Pallet Truck | Power Souce | AC Motor | |
| Rated Loading Capacity | 1000kg | Max. Lifting Height | 7500mm | |
| Min. Lifting Height | 140mm | Fork Length | 1070mm | |
| Fork Width | 100 | Overall Dimensions | 1070*100*35mm | |
| Certification | CE ISO9001 | After-sales Service Provided | Overseas third-party support available |
Product Description
Specifications
china forklift, TCAC driving motor;
1T load capacity,7500mm lift height
with advanced electric turret head
china forklift ;TC series;
1. With full hydraulic power steering system,using mechanical brake and electromagnetic regenerative brake to let fork turning 180 degree,move left or right by multiway vavle;
2. Rear axle locking device: to enhance the safety when fork lifting and side moving,to ensure the frame more stable during side stacking;
3. Mast Soft landing & shock absorption mast;the Speed at which the forks are lowered is reduced just Before the forks reach the ground (soft lading function),It’s can reduce the sound and shock experienced when the forks are lowered;
4.With fork HD display and drive wheel display,non-blind area,make it smoothest and easiest to use in the business;
5. With German Krupp Chanel steel,to ensure have high-strength and durable structure mast;
Rated load capacity: 1000kg, lift height: 7500mm;The min. width of aisle is 1510mm;
Model No. | TC10-75 |
Rated Capacity (KG) | 1000kg at 6000mm,750kg at 6000-7500mm |
Load Dimensions ---mm | 1250*1250 |
Operate Type | Stand-on |
Max. Lifting Height (MM) | 7500 |
Min. Turning Radius (MM) | 1880 |
Min. Stacking Aisle ---mm (1000*1000 Pallet) | 1480 |
Max Travel Speed km/h-laden/unladen | 7.0/8.0 |
Load center MM | 500 |
Fork Dimensions -L/W/T---mm | 1070*100*35 |
Shift Stroke (1000/1100mm pallet)--mm | 1060/1160 |
Lifting Speed (MM/S)-laden/unladen | 180/315 |
Rotating Speed of forks---s/180o | 12 |
Shift Speed ---mm/s | 240 |
Overall Length (MM) | 3454 |
Overall Width (MM) | 1450 |
Height-Overhead guard--mm | 2320 |
Height---Mast Lowered(MM) | 3750 |
Height-Mast Extended w/ Load-Backrest -mm | 8525 |
Fork Spread Range(MM) | 260-820 |
Min Ground Clearance--mm | 40 |
Max. Gradeability ---% | 10 |
Wheel Type | Polyurethane Solid Tyre |
Driving Wheel (MM) | Φ343×108 |
Balance Wheel (MM) | Φ180×76 |
Front Wheel (MM) | Φ140×100 |
Battery V/AH- Domestic BRAND | 48V /300 AH |
Service Brake | Mech. |
Parking Brake | Mech. |
Charger-Intelligent | 48V /50 A |
Driving Motor (KW) | 5.5 (AC) |
Lifting Motor (KW) | 7.5 |
ISO9001 Certificate;
If you have any requirements or suggestion on that,pls don't hesitate to contact with us.
