Home > Products > Electric pallet stacker > Electric Pallet Stacker(TBD Type)
Electric Pallet Stacker(TBD Type)
- Shanghai
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Anhui, China | |
| Brand Name | MIMA | Model Number | TBD10-30 | |
| Type | Powered Pallet Truck | Power Souce | DC Motor | |
| Rated Loading Capacity | 1000kg | Max. Lifting Height | 3000mm | |
| Min. Lifting Height | 2500mm | Fork Length | 1070mm | |
| Fork Width | 100mm | Overall Dimensions | 1988*850*2130MM | |
| Certification | ISO,SGS | After-sales Service Provided | Overseas third-party support available |
Product Description
Description:
Electric Pallet Stacker
TBC Series with DC driving motor, Rated load capacity: 1000kg, lift height: 3000mm;
1. TBC which has excellent performance, reasonable price, ad easy operate.
2. Four wheel design, balance wheel, it has good steady.
3. The frame is small, small turning radius, small stack aisle width.
4. Side long handle, easy operate, good view.
5. it has non-maintaince battery, improve working effiency.
Description | TBD10-30 |
Rated Load Capacity (KG) | 1000 |
Max. Lifting Height (MM) | 3000 |
Load center MM | 500 |
Overall Length (MM) | 1750 |
Overall Width (MM) | 800 |
Wheelbase (MM) | 1427 |
Height (MM)-Mast Lowered | 2090 |
Height (MM)-Mast Extended | 3570 |
Wheelbase mm | 1215 |
Tread( front/rear) mm | 400/525 |
Height (MM)-Fork Face | 86 |
Fork Size L×W (MM) | 1150*160 |
Outside Width--Fork(mm) | 560 |
Min. Turning Radius(mm) | 1400 |
Front Tread (MM) | 490 |
90°Stacking Aisle(MM) (1000*1200 Pallet)--Ast | 2250 |
Grade Ability % | 3/6 |
Travel Speed km/h-Laden/unladen | 3.5/4.0 |
Driving Wheel (MM) | Φ210*70 |
Front Wheel (MM) | Φ80*70 |
Battery V/AH-Domestic Brand | 2*12/80 |
Driving Motor (KW) | 0.65(DC) |
Lifting Motor (KW) | 2.0 |
Service Weight (with battery)?KG | 500 |
