Electric Stacker With Good Price
- shanghai
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Anhui, China | |
| Brand Name | MIMA | Model Number | TB | |
| Dimension(L*W*H) | 2045*850*2090 | Certification | CE | |
| Warranty | 12 months | After-sales Service Provided | Overseas third-party support available |
Product Description
electric stacker with good price ;
TB Series with AC driving motor, Rated load capacity: 2000kg, lift height: 4500mm;
1. Speed Limited for high position, to aviod the possibility of products' overturning when high speed in high position;
2. Curve safe control, the forklift will reduce the speed automatic when turning,to aviod the ejection of operator and products from the vehicle by the high speed;
3. Safe cutoff valve, to protect the operator and goods in well condition;
4. Vertical Drive system, to save the energy and have long time working;
5. Durability: Reinforced frame and mast have long service life;
6. Ergonomics multi-functional operation handle;
7. Initiative shocking proof system to reduce the operator' fatigue.
| Description Model No. | TB10-16 | TB15-25 | TB15-30 | TB10-35 | TB15-40 | TB20-45 |
| Rated Load Capacity (KG) | 1000 | 1500 | 1500 | 1000 | 1500 | 2000 |
| Load Capacity At Max. Height --KG | 1000 | 1500 | 1500 | 750 | 800 | 750 |
| Max. Lifting Height (MM)-H3 | 1600 | 2500 | 3000 | 3500 | 4000 | 4500 |
| Load center MM -C | 500 | 500 | 500 | 500 | 500 | 500 |
| Overall Length without pedal (MM)--L1 | 2040 | 2040 | 2058 | 2058 | ||
| Overall Width (MM) -b1 | 850 | 850 | ||||
| Overall Width with Traning wheels(MM) -b4 | / | 1250 | 1250 | |||
| Wheelbase (MM) --L3 | 1427 | 1427 | 1475 | |||
| Height (MM)-Mast Lowered--H1 | 2085 | 1805 | 2055 | 2305 | 2570 | 2820 |
| Free Lift Height (MM) --H2 | / | / | ||||
| Height (MM)-Mast Extended--H4 | 2085 | 3036 | 3536 | 4036 | 4551 | 5051 |
| Height (MM)-Fork Face --H5 | 90 | 90 | ||||
| Height (MM)-Pedal -H6 | 137 | 137 | ||||
| Height (MM)-Handle-H7 | 1470/970 | 1470/970 | ||||
| Front Overhang (MM)--L2 | 338 | 338 | ||||
| Fork Size L×W (MM) | 1150*190 | 1150*190 | ||||
| Outside Width--Fork(MM)--b3 | 680 | 680 | ||||
| Min. Turning Radius(MM)--Wa | 1725 | 725 | 1743 | |||
| Front Tread (MM)--b2 | 490 | 490 | ||||
| 90°Stacking Aisle(MM) (1000*1000 Pallet)--Ast | 2460 | 2460 | 2477 | |||
| Grade Ability % | 8 | 8 | ||||
| Travel Speed km/h-Laden/unladen | 4.0/5.8 | 4.0/5.8 | ||||
| Driving Wheel (MM) | Φ215*75 | |||||
| Balance Wheel (MM) | Φ150*50 | |||||
| Front Wheel (MM) | Φ80*70 | |||||
| Battery V/AH-Domestic Brand | 24/210 | |||||
| Charger V/A | 24/30 | |||||
| Driving Motor (KW) | 1.5 | 1.5 | ||||
| Lifting Motor (KW) | 2.0 | 2.0 | ||||
| Service Weight (with battery)?KG | 880 | 960 | 970 | 955 | 1070 | 1110 |
1.nude packing,wrapped by polybag;
2.Options: wooden pallet or wooden case;
1. 12 months warranty;
2. over-seas after-sale service if necessary;
Hefei Banyitong Science & Technology Developing Co., Ltd, established in 1994, we are professional manufacturer in material handling equipments and special logistic equipment, our brand "MIMA" have 12 series and 50 models according to long-time technology innovating and patent collection, including battery pallet truck, electric pallet stacker, reach truck, counterbalance forklift, electric tow tracotr, order picker, 4-directional forklifts, side-loading forklift and special logistic equipments, there are extensive used in Pharmaceutical, foodstuff, Chemical Industry, electronics Industry, Machinery Industry, Furniture,logistic industries etc;
If you have any requirements or suggestion on that,pls don't hesitate to contact with us.
