Home > Products > EDM Machine > CNC EDM Wire Cutting Machine Price
CNC EDM Wire Cutting Machine Price
- NINGBO
- T/T
You May Like
Product Details
| Condition | New | CNC or Not | CNC | |
| Place of Origin | Zhejiang, China | Brand Name | TOSUNNY | |
| Model Number | D-7135 | Voltage | 380V | |
| Power(W) | 1000w | Dimension(L*W*H) | 1450*1200*2100mm | |
| Weight | 500kg | Certification | ISO | |
| Warranty | 1 Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Precision EDM Machine D-7135,which adopts high precision DC servomotor with the funtion of PCC hand wheel,it is easier to remove the machine;D-7135 also adopts the prepressing high precision ball screw,with good rigidity.
Specifications:
Items | Unit | D-7135 |
Working table | mm | 350*630 |
Workilng groove | mm | 890*560*380 |
X axis travel | mm | 350 |
Y axis travel | mm | 250 |
Z axis travel | mm | 200 |
Working head travel | mm | 200 |
Spindle connect board to working table | mm | 700 |
Max. electrode weight | kg | 50 |
Max. workpiece weight | kg | 500 |
Overall dimension of work fluid container | mm | 1450*1200*2100 |
Net weight of machine | kg | 1350 |
Controller Specifications:
Items
| ZNC-EDM80A |
Max. machining current
| 80 |
Max. processing speed
| 500 |
Min. rate of electrode wear
| ≤0.2% |
Optinum roughness
| Ra<0.3 |
Max. power
| 9 |
Overall dimensions
| 540*800*1700 |
Net weight
| 200 |
we also have D-7125,D-7130,D-7145,D-7150 in stock.
