ARC250 Mosfet Inverter DC MMA 250 amps welding machine
- Shanghai
- Credit Card PayPal
You May Like
Product Details
| Condition | New | Place of Origin | Shanghai, China | |
| Brand Name | RONGYI | Model Number | ARC250 | |
| Arc Current | 250A | Pilot Arc Current | 5A | |
| Rated Duty Cycle | 60% | Motor Type | DC Motor | |
| Dimensions | 500*210*365 mm | Usage | MMA | |
| Voltage | 380V | Power(W) | 9.5 kVA | |
| Certification | CE,CCC, ISO9001, CE,CCC, ISO9001 | Warranty | 1 Year |
Product Description
FEATURES OF ARC250 Mosfet Inverter DC MMA 250 amps welding machine:
1. MOSFET inverter and precision constant current feedback control and technology, soft switch;
2. Wide working voltage range, strong adaptability to electricity power grid, high ability of interference resistance, stable welding current and steady arc;
3. Intensive arc, high welding speed, excellent welding performance, deep welding pool, less spatter, continuous current regulation, safety and reliable for operation;
4. Compact structure, portable, energy saving, easy for maintenance;
5. Applicable to various acid and basic welding electrodes;
6. Suitable for stainless steel, copper, cast iron, carbon steel, alloy metal, etc. ;
7. Complete accessories: welding torch, welding cable, earth clamp, welding holder.
PARAMETERS OF ARC250 Mosfet Inverter DC MMA 250 amps welding machine :
Model Spec. | ARC250 |
Power supply voltage | 3-Ph AC 380±10%V/ 50~60Hz |
Power supply capacity | 9.5 kVA |
No-load voltage | 56 V |
Out put current range | 10-250 A |
Power output voltage | 30.0 V |
No-load loss(W) | 60 |
Duty cycle | 60% |
Cosφ (η) | 0.93 |
Protection | IP 21 S |
Insulation grade | F |
Diameter of rod | 1.6-5.0 mm |
Net Weight | 18.5 kg |
Dimension (mm) | 500*210*365 |
* BUY WITH CONFIDENCE.
* QUALITY MACHINES MANUFACTURED BY RONGYI.
* FULL SERVICE AND PARTS BACK UP.
* 12 MONTHS WARRANTY.
The data in the above table is only for reference. Please subject to the name plate
on the device.
