HYY outdoor communication telephone cable wire
- SHENZHEN
- T/T
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | szrunxiang | |
| Model Number | RX-HYY Telephone Cable |
Product Description
Specifications
munication cable2.HDPE insulation
3.LDPE out sheated
4.Use in outdoor
5.delivery in time
HYY — Outdoor Telephone Cable UTP 25 Pairs 24AWG LDPE
SECTION DRAWING
HYY shielded outdoor communication telephone cable wire
SPECIFICATION
CABLE DESCRIPTION | |||
Conductor | Insulation | ||
Number of Pairs | 25 | Insulation Material | HDPE - Polyethylene |
Total Number of Conductors | 100 | Minimum Thickness | 0.15 mm |
Wire Gage | 24AWG | Diameter | Φ 0.85±0.02 mm |
Diameter | Φ 0.50±0.01 mm | Pair Color Code | Cable Color Cord |
Paired | Cabling | ||
Length of Lay | <155 mm | Order of the Pair | See the Cross Section |
Outer Sheath | |||
Outer Sheath | LDPE - Polyethylene | Outer Sheath Colors | Black |
Outer Sheath Rip Cord | 200D×3 | Min. Thickness | 0.80 mm |
Nominal Thickness | 1.00±0.05 mm | Diameter Over Sheath | Φ10.5±0.50 mm |
