Product Details
Place of Origin | Fujian, China | Brand Name | Joytone | |
Model Number | FT-7900R | Type | Vehicle Mouted | |
Dimensions | 100 x 52 x 32 mm | Frequency Range | 136-174/400-430MHz | |
Storage Channel | 128 | Talk Range | 15-30KM |
Product Description
Specifications
1.Dual band vehicle radio FT-7900R2.Ultra high frequency
3.High-quality
4.Warranty: six months
5.Shipment:DHL EMS UPS TNT
Dual band vehicle radio FT-7900R
High Power Output
Boasting a big 50 Watts of power output on 144 MHz, and 40 Watts on 430 MHz, the FT-7900E also includes provision for three lower power levels, so you never have to use more power than you really need. The power level is stored in regular and Hyper Memory registers, too
Wide Receiver Frequency Coverage
The FT7900E provides receiver coverage from 108 to 520 MHz, and 700 to 999.99 MHz (cellular blocked), so you have available a wide range of monitoring excitement, including AM Aircraft, Public Safety, Government, Business, and, of course, Amateur communications. The synthesizer steps appropriate for the operating band are automatically selected, too!
Large LCD Display
The large backlit LCD on the FT-7900E ensure excellent visibility
One-Touch
Five front panel keys allow complete transceiver configuration status to be stored for convenient one-touch recall. So you can set up favorite frequencies in each operating band, including the receive-only bands, and then recall them with a single touch of a button!
Over 1000 Memory Channels
The FT-7900E’s incredible memory channel capacity includes registers for over 1000 channels, each capable of storing a 6-character Alpha-Numeric label. And the memories may be stored in any of the 20 available memory groups; a particular memory channel may also be stored in multiple groups, if desired.
YSK-7800 Remote Mounting Kit (option)
Using the optional YSK-7800 Separation Kit, which contains both cabling and a bracket for the remote front panel, you can mount the FT-7900E’s front panel on the vehicle’s dash board, then stow the radio’s body under the seat or in some other convenient, out-of-the-way location. The cables are approximately 20 feet (6 m) in length.
WiRES™ Internet Linking Capability
The FT-7900E’s DTMF signaling capability includes provision for easy access to Yaesu’s WiRES™ (Wide-coverage Internet Repeater Enhancement System) Internet linking nodes, as well as other linking systems that require a DTMF string for access.
Yaesu FT-7900R Specification:
Specifications | FT-7900R |
GENERAL | |
Frequency Range | |
RX | 108.000 - 520.000 MHz |
700.000 - 999.990 MHz | |
TX | 144.000 - 146.000 MHz |
430.000 - 440 000 MHz | |
Channel Steps | 5/10/12.5/15/20/25/50/100 kHz |
Modes of Emission | F2A, F2D, F3E |
Antenna Impedance | 50Ω, unbalanced (Antenna Duplexer Built-in) |
Frequency Stability | ±5ppm @ -10ºC to +60ºC |
Operating Temperature Range | -20ºC to +60ºC |
Supply Voltage | 13.8 VDC (±15%), Negative Ground |
Current Consumption (approx.) | RX: 0.5A (Squelched) |
TX: 8.5A (144 MHz, 50W) | |
9.0A (430MHz, 45W) | |
Case Size (W x H x D, mm) | 140 x 41.5 x 168 (w/o knobs & connectors) |
Weight (approx.) | 1 kg |
TRANSMITTER | |
Output Power | 5/10/20/50 W (144 MHz) |
5/10/20/45 W (430 MHz) | |
Modulation Type | Variable Reactance |
Maximum Deviation | ±5 kHz, ±2.5 kHz |
Spurious Radiation | At least -60dB below |
Microphone Impedance | 2 kΩ |
DATA Jack Impedance | 10 kΩ |
RECEIVER | |
Circuit Type | Double-conversion Superheterodyne |
Intermediate Frequencies | 45.05 MHz / 450 kHz |
Sensitivity | 0.2µV for 12dB SINAD (137 - 150 MHz, FM) |
(see data sheet for other readings) | 0.2µV for 12dB SINAD (420 - 520 MHz, FM) |
Squelch Sensitivity | Better than 0.16µV |
Selectivity (-6dB / -60db) | 12kHz / 30kHz |
Maximum AF Output | 2W @ 8Ω for 10% THD |
AF Output Impedance | 4 - 16 Ω |
