Galvanized Preformed GUY-GRIP Dead-ends
- Shanghai
- T/T Credit Card
You May Like
-
Galvanized Steel Grounding Wire DEAD END
-
China High Strength Tension Dead-end for ADSS
-
Preformed Dead End Guy Grip, Galvanized Steel Wire Rope, High Quality
-
China (Mainland) High Quality Preformed (DG-) Stay Wire 3/8 Inch Guy Grips
-
High Quality Wire Dead-end For Adss/Opgw With Inner Rod
-
China Factory Direct Salesplastic Coated Galvanized Steetension Clamp/hot Dipped DEAD END
Product Details
| Place of Origin | Shanghai, China | Brand Name | shenyong,shenyong | |
| Model Number | DG- |
Product Description
Specifications
1.Preformed dead end clamps
2.Professional manufacture
3.factory direct price
4.ISO90012008
5.Timely delivery
|
GUY-GRIP Dead-ends, installed at the top, the breaker and the anchor, provide today’s most effective method for securing guy strand. This unique, one-piece dead-end is neat in appearance and free from bolts or high-stress holding devices. The GUY-GRIP Dead-end was the first to offer the cabled loop, a feature that provides more durabil- ity, easier tensioning and adaptability to multiple guying.
GUY-GRIP Dead-ends are made of the same material as the strand to which they are applied. They should be used on hardware that is held in a fixed position.The fitting should not be allowed to rotate or spin about the axis of the strand. They should not be used as tools including come-alongs, pulling-in grips, etc.
product model of the Company | standard model of the industry | Appliceble diameter of guide wire(mm) | Applicable type of guidu wire YB/T5004-1993(mm ² ) | Reference length of wire clamp(mm) | Wrie clamp weight(KG) | Color code | Matching fittings |
| SNL-25/G | NL-25/G | 6.60 | 25 | 635 | 0.22
| Yellow | Capel,adjustable wire,anti-theft ring clamp |
| SNL-35/G | NL-35/G | 7.8 | 35 | 711 | 0.30
| Black | |
| SNL-50/G | NL-50/G | 9.0 | 50 | 901 | 0.53
| Orange | |
| SNL-70/G | NL-70/G | 11.0 | 70 | 1016 | 0.82
| Green | |
| SNL-95/G | NL-95/G | 12.5 | 95 | 1333 | 1.50 | Orange | |
| SNL-100/G | NL-100/G | 13 | 100 | 1333 | 1.50 | Yellow | |
| SNL-120/G | NL-120/G | 14 | 120 | 1460 | 2.22 | Yellow |
Accessories :
2. Rich manufacture experience.
3. Certificates: ISO9001:2008
4. High quality with competitive price.
5. Domestic and Overseas markets.
6. Well equipped with complete facilities.
7. Strict quality control and excellent after-sales service.
8. In addition to supplying varieties of types and specifications to our customers, we also accept customized product. Please contact us with your detailed drawings, our well-trained serve staff and professional engineers will get back to you according to your requirement.
9,Our company has more than 13 years of production experience
10,Our engineers have more than 10 years of experience.
11.,The packing skilled more 10 years experience.
12,Our company has a professional design team and sales team(24 hours to provide you with quality service!)
Production process:
Shanghai Shenyong Line Products Co., Ltd. is an integrative economic and technical development limited company. It specializes in design, production and sales of line electric fittings oriented products. It also provides series of services to our customers, such as installation, reconstruction, maintenance of hoisting mechanical equipment; reconstruction and maintenance of electric control equipments; production and sales of structural parts; mechanical processing and business consultation etc.
FAQ
1. Design & Engineering
A.Experienced and skilled team of designers including CAD designers and 3D designers has the capacity to deliver outstanding designs for your project.
B.Simple design service is free of charge to all clients to ensure customer
If you require more complex engineering of structures such as overhead transmission and distribution lines design we can also provide this service also designer fee .
C. We look forward to delivering exceptional designs and advice for your project.
2. How to buy your ideal products?
A: You can provide us your drawing, and we will produce as your drawing. Or we can design as your requirements if you do not have a clear plan.
3. How to pay?
A: TT and L/C are acceptable and TT will be more appreciated.30% deposit before producing, 70% balance before loading by TT.
4. What is the delivery time?
A: It depends on order quantity.Generally, the delivery time will be within 15 to 30 days.
5. Package information?
A:For inner box and master carton are made as per international standards,and we can make special designed for you if need.And if necessary,will be packed in pallet to avoid any damage.
B:Not more than 35kg per carton box,about 1000kg per pallet
6.How long to make a sample?Is it free?
A:7 days depending on the sample‘s complexity.Normally,our sample is free
7.How to cantact us?
A:Send your inquiry details in the below,Click “send” now!
We promise
Honesty is our faith. We take our heart to deal with every order hoping that we can set up a long-term business relationship with you. We promise that we will provide you with products of high quality.
