ftp outdoor cat6 messenger cable stranded 110 block cat.6

Specifications

               ftp outdoor cat6 messenger cable stranded 110 block cat.6

FEATURE
High-Performance Data Communications Cable
This cable is Cat6 Outdoor CABLE UV Rated for outdoor use.
Suitable for 600MHz High-Speed Data Applications, Gigabit Ethernet,Fast Ethernet and 155Mbps TP-PMD/CDDI
Designed for Outdoor Installations UV Jacket (CMX) (UV)
Category-6 Unshielded Twisted Pair (UTP) Cable
4-Pair – Easily Identified Color-Striped Pairs
23 AWG Solid Bare Copper Conductors
Excellent Attenuation and Crosstalk Characteristics
Breaking Tension of the Messenger: 1370 Mpa
Maximum Hang Distance 70 Meters
Exceeds EIA/TIA 568 B.2-1
Sequential Length Markings on Jacket
Supplied in 1000´ Wooden Spool / Pull Box

Applications
Ideal for outdoor aerial applications
600MHz high speed data applications
Gigabit ethernet
Fast ethernet
155Mbps TP-PMD/CDDI
Physical Characteristics
 Conductor Size  23AWG
 Conductor Material Solid Bare Copper
 Insulation Material  High Density Polyethylene (HDPE)
 Insulation Diameter 1.02 +/- 0.3mm
 Number of Conductors 8 Conductors
 Number of Pairs  4 Pairs
 Messenger  1.2 mm Steel Wires
Outer Jacket Material  LDPE (RoHS Compliant)
Outer Jacket Diameter 6.6 / 2.6mm ± 0.4mm
 Outer Jacket Rip Cord Yes

Technical Diagram

Pair Color Code Chart
Pair 1 ----- White/Blue Stripe & Blue
Pair 2 ----- White/Orange Stripe & Orange
Pair 3 ----- White/Green Stripe & Green
Pair 4 ----- White/Brown Stripe & Brown

Mechanical Characteristics

Storage Temperature Range: N/A

Installation Temperature Range: N/A

Operating Temperature Range: N/A

Bulk Cable Weight: 43 lbs. / 1000FT

Max. Recommended Pulling Tension: N/A

Min. Bend Radius/Minor Axis: N/A

Min. Bend/Installation: N/A

Test Object: Jacket

Test Material: PVC

Before Tensile Strength: ≥10.0

Aging Elongation: ≥350

Aging Condition: 100°C x 24hrs x 10Days

After Tensile Strength:≥12.5

Aging Elongation:≥300

Cold Bend: No Visible Cracks (-20°C ± 2°C x 4h)

Electrical Characteristics

Maximum Unbalanced to ground capacitance: N/A

Nominal Velocity of Propagation: N/A

Maximum Delay: 537.60 @ 100MHz (ns/100m)

Maximum Delay Skew: ≤ 45 (ns/100m)

Maximum Conductor DC Resistance: 9.5 (@ 20°C OHm/100m)

Maximum Operating Voltage - UL: N/A

Maximum DCR Unbalanced: 5% (@ 20°C)

Attenuation (Maximum)

39.79dB/100m (328.1ft.) @ 350MHz

54.49dB/100m (328.1ft.) @ 600MHz

1.0 - 100MHz Impedance: 100Ω ± 15%

NEXT (Minimum)

36.1dB/100m (328.1ft.) @ 350MHz

32.6dB/100m (328.1ft.) @ 600MHz

PS-NEXT (Minimum)

34.1dB/100m (328.1ft.) @ 350MHz

30.6dB/100m (328.1ft.) @ 600MHz

Return Loss (Minimum)

16.3dB/100m (328.1ft.) @ 350MHz

14.7dB/100m (328.1ft.) @ 600MHz
