Simple Industrial Oil Purifiers for Engineering Machinery With Membrane Filtration

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Dalian Port
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Flow	40L/min
Working Pressure	0.2~0.35Mpa	Place of Origin	Liaoning, China
Brand Name	Jing Yuan	Model Number	JY-M50
Usage	Insulation Oil	Voltage	380V/220V
Dimension(LWH)	550560920mm	Weight	77KG
Certification	ISO9001:2008	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Simple industrial oil purifiers for engineering machinery with membrane filtration

Product Description

Excellent performance:

•New polymer membrane filtration technology

•Selectivity characteristics of polymer membrane is core technology.

•Oil-water separating is easy.

•High precision and deep filtration

•Guarantee the cleanness index of industrial oil

•Improve the efficiency of the engine

•Prolong engine service life

•The cost of filtration is low

Technical Parameters	1	Model Number	JY-M50
	2	Working Pressure	0.2~0.35Mpa
	3	Flow Rate	40L/min
	4	Filtration Precision	2,5,10,15,25μm
	5	Filtration Material	HDPE,PA
	6	Applicative Oil	Industrial Oil
	7	Chemical Resistance	Widely Chemical Compatibility
	8	Type of Filter element	J22-330H
	9	Power	220/380V Electrical Engine
	10	Dimension	550×560×920mm
	11	Weight	77KG
	12	Service Life of Filter Element	2~3 Year
	13	Warranty for Main Engine	1 Year
Functional Characteristics	1	Large flow diesel purification filter
	2	Polymer 3D mesh structure membrane filter element
	3	High precision two-level filtration
	4	High interception rate
	5	Oil-water separation
	6	Potable trolley structure
	7	Providing rapid fuel filtration service on site
	8	Circulating filtration for oil storage tank
	9	Made of high quality thick steel plate, anti-corrosion treatment
	10	Minimum mechanical flow resistance
	11	Low pressure difference
	12	Low power consumption
	13	easy to clean
	14	Low operating cost
	15	Design life is more than 20 years (except for filter element)
Principle	Selectivity characteristic is to say, the oil molecules will pass and water molecules or impurities will be intercepted, so that the oil and water can be separated.
Application	Factories, mines, mechanical processing, engineering machinery, auto repair and other industries in Asia, South America, Africa and Middle East.
Services	We have our own factories and our own international sales team, we could satisfy you with our high quality products ,fast delivery and most important ,competitive price. We adhere to the philosophy of "Quality is the life,the credibility of the first,customer first".

Application in generating units and industry

Our membrane element

Company information:

Shenyang Jingyuan Membrane Co.,Ltd. is a professional and innovative membrane filter manufacturer,specialized in clean diesel filter technologh,special membrane production technology,supplying with high performance and large flow of diesel purification filters and devices, industrial oil purification device, high proformance military filtration device. we are particularly skilled in research and application of membrane filtration materials, strict product quality control. we uphold the proprietary technology and creative and offer you qualified products,competitive price and professional services. we sincerely hope to promote and develop the business with our friends on the basis of equality and mutual benefit. Philosophy:Focus on research and development,continously innovate product,control quality in strict,base on equality and mutual benefit.

Packaging & Transportation

1>Durable Plywood Case packaging suitable for long distance ocean/train transportation.

2>Appointed shipping company could be used in shipment.

3>Whole process monitoring insures the safety of goods unitl arrival.

Application

Our services---Term of Warranty:

We have our own factories and our own international sales team, we could satisfy you with our high quality products ,fast delivery and most important ,competitive price. We adhere to the philosophy of "Quality is the life,the credibility of the first,customer first".

1. One year with spare parts and service.

2. Engineers available to service machinery for overseas.
