Solid 2014 Portable Ultrasonic Pulse Velocity

Specifications

Solid 2014 portable ultrasonic pulse velocity

1,Touch screen operation simplify the test process simple and quick.

2,Voice announcing and text prompts is extremely friendly to users.

3,Instrument has a variety of helping documents and video presentations of how to operate the instrument.

Mass storage

4,2GB SD can store more than 100,000 measurement results.

Low-carbon energy

5,Rechargeable highly efficient lithium batteries decreases power consumptions.

Main technical parameters:

  1,Based ARM9 embedded hardware platform, WinCe 5.0

     Operating   System, true-color TFT display with touch screen

  2,Number of channels: 2

  3,Receiving Sensitivity: ≤ 10μV

  4,Amplifier bandwidth: 5Hz ~ 500kHz

  5,Amplitude range: 0 ~ 177dB

  6,Transmit time measurement: 0.025us ~ 19999.9μs

  7,Transmit time measurement resolution: 0.025μs

  8,Transmit measurement accuracy: ≤ ± 0.05μs

  9,Maximum sampling length: ≤ 64KB

  10,Sampling rate: 40Msps per channel

  11,Power supply: Rechargeable lithium battery

  12,Battery hours : ≥ 28 working hours

  13,Ambient temperature range: -10 °C ~ +50 °C

  14,Working humidity: ≤ 90% RH

 Packaging & Shipping

Our Services

Company Information

We established in 2006. We are a professional manufacturer for non-destructive testing (NDT) instruments which includes hardness tester, ultrasonic thickness gauge, ultrasonic flaw detector etc.

FAQ
