Beer brewing kit 500L,commercial beer brewery equipment,copper pub beer making equipment

Beer brewing kit 500L,commercial beer brewery equipment,copper pub beer making equipment

HL-beer equipment-Mainly Products Range:

1)Hotel Micro brewing factory

2)Pub Mini Beer Brewery equipment

3)Home mini beer brewery equipment

4)Restaurant & Barbecue beer brewing system

5)Large beer brewing factory

We can supply 50L,100L, 200L, 300L, 500L, 1000L, 2000L, 3000l, 5000l capacity beer machine.

We also produce laboratory brewery and customize according to your requirements.

SD-beer brewery equipment Specifications

1. ISO9001:2000
2. advanced German beer production technology
3. stainless steel 304 or red copper
4. 5 years warranty

SD-beer fermenter fermentor for beer brewing

The whole set equipment is made of international stainless steel. The cooling jacket adopts the form of honeycomb jacket. The jackets are provided at tank body and conical bottom to effectively increase the cooling speed. Heat exchanging area of jacket of different properties can be allocated according to customers’ technological requirements. Small 60 deg conical bottom which is designed for fermenting and improving beer, as well as breeding yeast. PU heat preservation is adopted, and the external coating is made of fully welded stainless steel sheet. Manhole, CIP cleaning, temperature connection and sampling vent etc. Accessories are available.

1. 1.     working capacity:25bbl
2. 2.     packing size(L*W*H): 1160mm*1360mm*2410mm
3. 3.     Net weight:310kgs, Gross weight:315kgs
4. 4.     All international standard 304 stainless steel.
5. 5.     Fully welded exterior.
6. 6.     Dual zones for cooling
7. 7.     Double walls, jacketed & insulation.
8. 8.     Choice of side or top manway.
9. 9.     Four legs support, adjustable feet.
10. 10.   60 degree cone
11. 11.   25% free headroom
12. 12.   15 PSI operating pressure
13. 13.   Rotating racking arm
14. 14.   CIP & spray ball
15. 15.   Pressure/vacuum relief valve, thermowell
16. 16.   All clamps, valves and fittings
17. 17.   Including 2pc of SS 304 butterfly valves

Main markets: USA, CANDA, AUSTRALIA, NIGERIA, INDIA and so on

After sale service:

1.Providing beer production technology, brewing formula and person training service.

2. Providing cost analysis, brew house design, equipment production.
3.Main machine guarantee for 3 years.

We adopted the international standards of fermentation technology, diverse methods to control the temperature, the inner surface of the tank are mirror-polished.

welcome to contact me for more details!
